电池工业用纯水设备、去离子水设备
应用领域和指标要求参考
Reference of applications areas and indexes required
用途Applications | 用水指标Water Indicators | 参考标准Reference standard |
蓄电池、锂电池、锌锰电池生产、太阳能电池、锂电池正极材料 | 电阻率5 ~10 MΩ.CM | 我国电子级水质技术指标,GB11446-1-1997 |
主要工艺流程和出水指标:
Main technical process and standard of output water
※预处理+反渗透+离子交换器(电阻率≥15MΩ.CM)
Pre-treatment+ stage reverse osmosis system+ion exchange (electric conductivity≥15MΩ.CM)
※预处理+二级反渗透+EDI(电阻率≥15MΩ.CM)
Pre-treatment+ stage reverse osmosis system+EDI (electric conductivity≥15MΩ.CM)
※ 预处理+二级反渗透+脱气膜+EDI +抛光混床(电阻率≥18.25MΩ.CM)
Pre-treatment+ double stage reverse osmosis system+air film+EDI +polishing mixed bed (electric conductivity≥18.25MΩ.CM)
详细工艺需根据原水设计情况进行设计
Details of the design process should be carried out according to the feed water quality.



纯水设备的主要特点
Main technics of pure water treatment equipment
▼结合电子工业用水连续生产的特性,采用了全膜法处理工艺(UF+RO+EDI)完成高纯水的制备工作; The electronics industry with the characteristics of continuous production of water, using the entire membrane treatment process (UF + RO + EDI) to complete the preparation of highly pure water work; ▼对于电子行业用水的特性,增强了对水中二氧化硅、重金属和有机碳的脱除; For the water features of electronics industry , enhanced to removal silica, heavy metals and organic carbon in water. ▼采用了氮封水箱解决了电子工业用水要求较高,水的储存容易污染问题; Using nitrogen sealed water tanks to solve the problems of electronics industry require a higher water use, water storage easy to pollution ; ▼采用进口反渗透膜,脱盐率高,使用寿命长,运行成本低廉,产水水质高而稳定; Adopted import reverse osmosis membranes, desalination rate is high, long service life, the operation cost is low, the output water quality is high and stable. ▼在线水质监测控制,实时监测水质变化,保障水质安全; On-line water quality monitoring and control, real-time monitoring of water quality to ensure safety of water quality. ▼全自动电控程序,还可选配触摸屏操作,使用方便,操作简单、安全; Automatic control procedure, also equipment with touch screen operation, easy to use, the operation is simple, safe. ▼切合当地水质的个性化设计,设想周到的堆叠式设计,占地面积小,全方位满足需求。 Correspond with the local water personalized design, considerate stackable design, small floor area, which can meet considerate needs. ▼运行费用及维修成本低,全自动运行,实现无人化管理操作。 Operating costs and maintenance cost low, automatic operation, can realize unmanned management operations. |
