1.包装机技术规格Packa  ging Machine Specification

1．PLC控制系统

2．能够自动完成填充、制袋、封合、切断、计数、切易撕口、打印生产日期等功能

3．包装物料：液体类

4制袋形式：三边封、四边封或背封

5．包装膜总宽度140 mm

6．切口形式：单包一切（花纹刀）

7．包装速度：35-55包/分

8．包装精度：1%

9．机体表面均为201不锈钢，与物料接触部分为304不锈钢

10．生产日期：2*3  8位在横封上

11．电压：220V单相50HZ

12．机器外形尺寸：750mm×700mm×1800mm

13．包装膜卷直径：30CM

14．机器配置：PLC---三菱 气动元件：台湾亚德克   拉袋电机 南京华兴   接触器 正泰

1. PLC control system
2. Able to automatically fill, bag, sealing, cutting, counting, cutting easy tearing mouth, print production date etc.
3. Packaging materials: Liquid
4 bag type: three letters, four sides sealing or back seal
5. The total width of 140 mm Packaging Film
6. Incision in the form: a single package all the (pattern cutter)
7. Packing speed :35-55 bags / min
8. Packaging accuracy: 1%
9. Surfaces are 201 stainless steel body with 304 stainless steel material contact parts
10. Production Date: 2 * 3 8 in the transverse seal
11. Voltage: 220V single phase 50HZ
12. Overall dimensions: 750mm × 700mm × 1800mm
13. Packaging Film roll diameter: 30CM
14. Machine configuration: PLC --- Mitsubishi pneumatic components: Taiwan, Asia and Germany Nanjing Huaxing carat bags motor contactor Chint

适用于食品、医药、化工产品中的液体或膏状物袋包装，如：洗头水、油、酱、面霜、液体化肥等，适合于大中小各类企业的自动化生产。

For food, medicine, chemical products, liquid or paste in the bag, such as: shampoo, oil, butter, cream, liquid fertilizer, suitable for medium and small enterprises of all types of automated production.

量身订做，可以根据包装物的特性专门设计。

Customized, according to the characteristics of the packaging is designed.

优惠政策：销方首次免费上门安装调试，并代培操作人员，平时操作不顺可以来电咨询，需技术人员上门修理的我们会尽快出发，整机保修壹年，终生维修，长期优惠供应零配件。

Preferential policies: the first time, free home sales installation, and conferred to operators, usually operating ring true to call to consult, need home repair technicians will start as soon as possible, the whole year warranty, lifetime maintenance, long-term supply of spare parts offer .

同时，我们也可以代包洗头水，有需要的请联系，谢谢！

Same time, we may be able to package shampoos, there is a need, please contact, thank you!
