Product Features
◆1 channels GPS L1 C/A code
◆Doppler control 10KHz to -10KHz in 1Hz step
◆Almanac data upgradeable
◆GPS production test turnkey solution
◆Sensitivity testing
◆ Built-in ultra high precision OCXO
◆ RF Level from -90 dBm to -145 dBm in 1 dB step
◆ Support multiple DUT connectivity (typ. 4 DUT)
◆ Firmware upgrading possible for various GPS chipset

support

SPECIFICATION
Output GPS Frequency
L1 1575.42MHz
Frequency accuracy
+/- 0.01ppm
Phase Modulation
BPSK
Channels
1 channels
NAV Data
GPS C/A code @50 bps
Output RF Level
-90 dBm to -145 dBm in 1 dB step
RF control
ON/OFF/CW
Doppler Control
-10KHz to +10KHz in 1 Hz step
RF GPS connector
SMA type
Master Oscillator
Frequency: 10.23MHz
Thermal stability:
0.02ppm @ -30 ~ +70oC
Aging:
0.1ppm/yr (0.001ppm/day)
Phase noise:
-85dBc/Hz @1Hz
-140dBc/Hz @100Hz
-150dBc/Hz @10KHz
Short-term stability:
1.0E-011 @ 1 sec
0.0E+000 @ 10 secs
Interface
USB / Ethernet
Operating Temperature
0 ~
