| 类型 | 平板硫化机 | 型号 | XLB-Q3000*3000 |
| 样式 | 立式 | 运行方式 | 全自动硫化机 |
| 品牌 | 金港湾 | 宽度 | 3000（㎜） |
| 行程 | 1000（㎜） | 公称合模力 | 30.0（MN） |
参数 型号 | XLB-1100*5700 | XLB-1400*5700 | XLB-1400*10000 | XLB-1600*11600 | XLB-1600*10000 | XLB-2000*10000 |
热板规格 | 1100*5700 | 1400*5700 | 1400*10000 | 1600*11600 | 1600*10000 | 2000*10000 |
总压力 | 17.55MN | 25.00MN | 49.00MN | 49.80MN | 56.00MN | 70.00MN |
热板压力 | 2.8 Mpa | 3.13 Mpa | 3.5 Mpa | 3.3 Mpa | 3.5 Mpa | 3.5 Mpa |
柱塞直径 | 500 mm | 360 mm | 450 mm | 450 mm | 450 mm | 600 mm |
柱塞个数 | 5 | 10 | 20 | 20 | 18 | 16 |
柱塞行程 | 520 mm | 400 mm | 300 mm | 300 mm | 400 mm | 300 mm |
热板层数 | 2层 | 2层 | 1层 | 1层 | 2层 | 1层 |
夹持力 | 0.50 | 0.72 | 0.90 | 1.20 | 1.20 | 1.20 |
拉伸力 | 0.40 | 0.60 | 0.80 | 0.90 | 1.10 | 1.00 |
蒸汽压力 | 0.63 Mpa | 0.63 Mpa | 0.63 Mpa | 0.63 Mpa | 0.63 Mpa | 0.63 Mpa |
冷却压力 | 0.3 Mpa | 0.3 Mpa | 0.3 Mpa | 0.3 Mpa | 0.3 Mpa | 0.3 Mpa |
控制方式 | PLC | PLC | PLC | PLC | PLC | PLC |
用 途 | 输送带 | 输送带 | 输送带 | 输送带 | 输送带 | 输送带 |
|
|
|
|
|
|
|
该机使用于硫化普通橡胶输送带、尼龙输送带/PVG输送带、钢丝绳输送带等织物芯平行胶带。主机为框式结构，热板及柱塞均为选用优质材料，加工精密，不易磨损，不易腐蚀，维修方便，工作压力稳定，调整方便。该机采用PLC控制，硫化过程可实现多程序自动化控制，可自动检测和调节热板温度，提高了平板硫化机组控制水平，降低了劳动强度，提高了生产效率。
Type plate vulcanizing XLB model Q3000 - * * * * 3000
Pattern of vertical automatic machine operation
Brand golden harbor maximum width 30 (mm),
Maximum 10 (mm) travel nominal mould 30.0 force (MN)
Parameter model
XLB - 1100 * 57
XLB - 1,400 * 57
XLB - 1,400 * 10,000
XLB - 16 11600 *
XLB - 1600 * 10,000
XLB - 2000 * 10,000
Hot plate specifications
1100 * 57
14 * 57
14 * 10,000
16 11600 *
16 * 10,000
2000 * 10,000
Total pressure
17.55 MN
25.00 MN
49.00 MN
49.80 MN
56.00 MN
70.00 being MN
Hot plate stress
2.8 Mpa
3.13 Mpa
350 Mpa
3.3 Mpa
350 Mpa
350 Mpa
Diameter of piston
500 mm
360 mm
45 mm
45 mm
45 mm
600 mm
Number of plunger
5
10
20
20
18
16
Piston stroke
520 mm
400 mm
300 mm
300 mm
400 mm
300 mm
Hot plate layer
Layer 2
Layer 2
1
1
Layer 2
1
Clamping force
0.50
0.72
0.90
1.20
1.20
1.20
Tensile strength
0.40
0.60
0.80
0.90
1.10
1.00
The steam pressure
0.63 Mpa
0.63 Mpa
0.63 Mpa
0.63 Mpa
0.63 Mpa
0.63 Mpa
Cooling pressure
0.3 Mpa
0.3 Mpa
0.3 Mpa
0.3 Mpa
0.3 Mpa
0.3 Mpa
Control mode
PLC
PLC
PLC
PLC
PLC
PLC
By way
belt
belt
belt
belt
belt
belt
The ordinary rubber vulcanization used in belt conveyor, nylon rope belt conveyor, PVG/fabric such as core parallel tape. Host for frame structure, the hot plate and piston are using high quality materials and the processing precision, easy wear and corrosion, convenient maintenance, working pressure stability, convenient adjustment. This machine adopts PLC control, vulcanization process can achieve more procedure control, automation automatic detection and adjusting temperature of the hot plate, improving the curing press control level, reduce the labor intensity, improve the production efficiency.
