KDG空气等离子切割机
| 型号 | KDG50 | KDG80 | KDG120 | KDG160 | KDG200 | KDG300 |
| 额定输入电压 | 3-380V/50HZ | 3-380V/50HZ | 3-380V/50HZ | 3-380V/50HZ | 3-380V/50HZ | 3-380V/50HZ |
| 额定输入电容 | 7KVA | 12KVA | 18KVA | 25KVA | 50KVA | 60KVA |
| 负载持续率 | 60% | 60% | 60% | 60% | 60% | 60% |
| 切割电流、档级 | 50A | 40/80A | 60/120A | 120/160A | 100/200A | 160/300A |
| 额定负载电压 | 120V | 120V | 120V | 120V | 120V | 120V |
| 焊据冷却方式 | 空气冷却 | 空气冷却 | 空气冷却 | 水冷却 | 水冷却 | 空气水 |
| 最大切割厚度—碳钢 | 16mm | 25mm | 35mm | 40mm | 50mm | 60mm |
| 最大切割厚度—铝 | 8mm | 20mm | 25mm | 30mm | 40mm | 50mm |
| 最大切割厚度—铜 | 6mm | 10mm | 15mm | 20mm | 25mm | 35mm |
| 压缩空气压力 | 3-6kgf/cm^2 | 3-6kgf/cm^2 | 3-6kgf/cm^2 | 3-6kgf/cm^2 | 3-6kgf/cm^2 | 3-6kgf/cm^2 |
| 重量 | 80kg | 110kg | 130kg | 160kg | 200kg | 250kg |
| 外形尺寸(长宽高) | 560*520*720 | 560*520*720 | 680*550*900 | 680*550*900 | 1200*650*1000 | 1200*650*1000 |
1、高频引弧，引弧容易
2、切割速度快，割缝窄
3、仅用压缩空气作气源，切割成本低
