Applications
• Designed for primary use in the
Semiconductor industry for transfer of highly aggressive ultrapure chemicals and
de-ionized water
• UPM 1000 series valve is ideal for applications that
demand high-pressure capabilities and a high Cv flow
factor

Operation
• Manually operated on/off valve, quarter
turn
• Designed to handle up to 100 PSIG (690 kPa)
pressure

Notes
When selecting either Flare Grip® or Grab Seal™
ends, we recommend end connections that are larger than the valve orifice size
in order to achieve full flow.
This product is class 100 clean room assembled
and double bagged.
Leak detection port on side has standard port size of 1/4
-28.

For applications in concentrated HCI (Hydrochloric Acid) please
consult the factory.
