LED Driver 12V5A

LED Driver 12V5A
Item No.: FY1205000

  Features/ Functions
Regulated output with low ripple
Sensing and following the rating voltage of LED strips
Constant output current option
Power on LED indicator
Modified and custom designs
Comply with CEC ,MEPS, EuP
Certifications: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick, RoHS

  General Specifications
Input :100-240VAC, 50/60Hz
Output voltage : 12 VDC
Output current: : 5000 mA
Ripple : 350 mVp-p Max.
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 85% the Min.
Operating temperature: -29℃～+45.5℃
Storage temperature: -40℃～+75℃
Operating relative humidity: 5%～95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load operation at 25℃
Case dimension: 134X59X31.5mm
Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; NIN 2.5
