适用范围：
适用于输送不含固体颗粒和纤维.无腐蚀性.温度不高于80度.粘度为5~1500cst的润滑油或类似的其它液体.并适用于液压传动系统.
结构特点:
齿轮采用具有国际九十年代先进水平的新技术双圆弧正玄曲线齿型圆弧.与渐开线齿轮相比优点是齿轮合过程中没有相对滑动.所以齿面无磨损.运转平衡.无困液现象.噪音低.寿命长、效率高.
性能参数：
型号 | 流量
Q | 转速
n
r/min | 排出压力
p
Mpa | 必需汽
蚀余量
r
m | 效率
η
% | 电动机 |
m3/h | 频率
Hz | 功率KW | 型号 |
YCB0.6-0.6 | 0.6 | 910 | 0.6 | 5.5 | 32 | 50 | 0.75 | Y90S-6 |
1.0 | 1390 | 50 | 0.75 | Y80L2-4 |
0.7 | 1130 | 60 | 0.75 | Y90S-6 |
1.2 | 1710 | 60 | 0.75 | Y80L2-4 |
YCB0.6-1.6 | 0.6 | 910 | 1.6 | 7.0 | 70 | 50 | 1.1 | Y90L-6 |
1.0 | 1400 | 50 | 1.5 | Y90L-4 |
0.7 | 1130 | 60 | 1.1 | Y90L-6 |
1.2 | 1710 | 60 | 1.1 | Y90S-4 |
YCB1.6-0.6 | 1.6 | 910 | 0.6 | 5.5 | 42 | 50 | 0.75 | Y90S-6 |
2.5 | 1400 | 50 | 1.1 | Y90S-4 |
1.9 | 1130 | 60 | 1.1 | Y90L-6 |
3.0 | 1710 | 60 | 1.5 | Y90L-4 |
YCB1.6-1.6 | 1.6 | 940 | 1.6 | 7.0 | 71 | 50 | 2.2 | Y112M-6 |
2.5 | 1440 | 50 | 4 | Y112M-4 |
1.9 | 1150 | 60 | 2.2 | Y112M-6 |
3.0 | 1750 | 60 | 4 | Y112M-4 |
YCB3.3-0.6 | 3.3 | 940 | 0.6 | 5.0 | 60 | 50 | 1.5 | Y100L-6 |
5.0 | 1420 | 50 | 2.2 | Y100L1-4 |
4.0 | 1150 | 60 | 1.5 | Y100L-6 |
6.0 | 1730 | 60 | 2.2 | Y100L1-4 |
YCB3.3-1.6 | 3.3 | 960 | 1.6 | 7.0 | 72 | 50 | 5.5 | Y132M2-6 |
5.0 | 1440 | 50 | 7.5 | Y132M-4 |
4.0 | 1170 | 60 | 4 | Y132M1-6 |
6.0 | 1750 | 60 | 7.5 | Y132M-4 |
YCB4-0.6 | 4.0 | 940 | 0.6 | 5.0 | 60 | 50 | 1.5 | Y100L-6 |
6.0 | 1420 | 50 | 2.2 | Y100L1-4 |
4.8 | 1150 | 60 | 2.2 | Y112M-6 |
7.2 | 1730 | 60 | 3 | Y100L2-4 |
YCB4-1.6 | 4.0 | 960 | 1.6 | 7.0 | 72 | 50 | 5.5 | Y132M2-6 |
6.0 | 1440 | 50 | 7.5 | Y132M-4 |
4.8 | 1170 | 60 | 5.5 | Y132M-6 |
7.2 | 1750 | 60 | 7.5 | Y132M-4 |
YCB8-0.6 | 8.0 | 960 | 0.6 | 5.0 | 61 | 50 | 3 | Y132S-6 |
12.0 | 1440 | 50 | 5.5 | Y132S-4 |
9.6 | 1170 | 60 | 4 | Y132M1-6 |
14.4 | 1750 | 60 | 5.5 | Y132S-4 |
YCB8-1.6 | 8.0 | 970 | 1.6 | 7.0 | 75 | 50 | 11 | Y160L-6 |
12.0 | 1460 | 50 | 15 | Y160L-4 |
9.6 | 1170 | 60 | 11 | Y160L-6 |
14.4 | 1760 | 60 | 15 | Y160L-4 |
YCB10-0.6 | 10.0 | 960 | 0.6 | 5.0 | 62 | 50 | 4 | Y132M1-6 |
15.0 | 1440 | 50 | 5.5 | Y132S-4 |
12.0 | 1170 | 60 | 5.5 | Y132M2-6 |
18.0 | 1750 | 60 | 7.5 | Y132M-4 |
YCB10-1.6 | 10.0 | 970 | 1.6 | 7.0 | 76 | 50 | 11 | Y160L-6 |
15.0 | 1470 | 50 | 15 | Y160L-4 |
12.0 | 1170 | 60 | 11 | Y160L-6 |
18.0 | 1770 | 60 | 18.5 | Y160L-4 |
YCB20-0.6 | 20.0 | 970 | 0.6 | 5.0 | 68 | 50 | 7.5 | Y160M-6 |
24.0 | 1170 | 60 | 7.5 | Y160M-6 |
YCB25-0.6 | 25.0 | 970 | 0.6 | 5.5 | 69 | 50 | 11 | Y160L-6 |
30.0 | 1170 | 60 | 11 | Y160L-6 |
YCB30-0.6 | 30.0 | 970 | 0.6 | 5.5 | 70 | 50 | 11 | Y160L-6 |
36.0 | 1170 | 60 | 11 | Y160L-6 |
YCB40-0.6 | 40.0 | 970 | 0.6 | 5.5 | 72 | 50 | 15 | Y180L-6 |
48.0 | 1180 | 60 | 15 | Y180L-6 |
YCB50-0.6 | 50.0 | 970 | 0.6 | 5.5 | 72 | 50 | 22 | Y200L2-6 |
60.0 | 1180 | 60 | 22 | Y200L2-6 |
