公称压力：2.5Mpa
适用温度范围：-20-232-350，
适用介质：水、油、气及某些腐蚀性液体（ W.O.G ）
螺纹类型：G.NPT.BSPT.BSP.DIN259/2999
| NO. | 类型 | 尺寸 | 数量 | 压力 | 连接 | 材质 | 结构长度 (mm) | | |
| 体 | 板 | 座 | 杆 | | |
| 1 | 闸阀 | 1/2 | 25 | 600 | 内螺纹 | F304 | F304 | F304 | F304 | 79 | 175 | 4375 |
| 2 | 3 WAY T-ball valve | 3/4 | 10 | 600 | 内螺纹 | F304 | F304 | PTFE | F304 | | | |
| 3 | 3 WAY T-ball valve | 1/2 | 10 | 600 | 内螺纹 | F304 | F304 | PTFE | F304 | | | |
| 4 | 闸阀 | 1/4 | 1 | 600 | 法兰 | F304 | F304 | F304 | F304 | 887 | | |
| 5 | 闸阀 | 3/4 | 20 | 600 | 内螺纹 | F304 | F304 | F304 | F304 | 92 | 195 | 3900 |
| 6 | 闸阀 | 2 | 8 | 600 | 法兰 | F304 | F304 | F304 | F304 | 292 | 1496 | 11968 |
| 7 | 闸阀 | 2 | 2 | 300 | 法兰 | LC2 | LC2 | LF2 | F304 | 216 | | |
| 8 | 闸阀 | 1 | 10 | 600 | 内螺纹 | F304 | F304 | F304 | F304 | 111 | 290 | 2900 |
| 9 | 闸阀 | 11/2 | 4 | 600 | 内螺纹 | F304 | F304 | F304 | F304 | 120 | 509 | 2036 |
| 10 | 闸阀 | 1 1/2 | 2 | 600 | 法兰 | F304 | F304 | F304 | F304 | 241 | 998 | 1996 |
| 11 | check valve | 2 | 2 | 150 | 法兰 | LC2 | LC2 | LF2 | F304 | 203 | | |
| 12 | gate valve | 12 | 1 | 600 | 法兰 | CF8 | CF8 | CF8 | F304 | 838 | | 27175 |
| 13 | check valve | 14 | 2 | 600 | wafer | CF8 | CF8 | CF8 | F304 | 273 | | |
| | | | | | | | | | | | | |
