2 cell Li-ion battery charger 8.5V0.3A

3 cell Li-ion battery charger 12.6V1A PSE
Item No.: FY1261000

  Features/ Functions
Reverse polarity protection
Continuously monitoring battery voltage
Constant output current to provide protection
Terminating the charge once battery is full
With a dual color LED indicator
Safety standard approvals: UL, CUL, PSE, CB, FCC

  General Specifications
Input :100-240VAC, 50/60Hz
Output voltage : 9～12.6  VDC
Output current :  1000 mA+/-10%
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 80 % Min.
Temperature: Case 65 ℃ Max.
Operating temperature: -29℃ ～ +45.5℃
Storage temperature: -40℃ ～ +75℃
Operating relative humidity: 5%～95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
Overheat protection design
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; NIN 2.5
