Model No：KFL8038
SIZE：80×80×38mm
CONSTRUCTION：
●Die-cast aluminum housing ●Glass fiber reinforced plastic impeller，UL 94V-0 rating ●Impedance protected ●Leader wire or terminal is available
OPERATING TEMPERATURE：
Ball Bearing	-30℃to + 75℃
Sleeve Bearing	-10℃to + 70℃
WEIGHT：
0.34 Kg

规格型号 Model No.	轴承 Bearing	电压 Voltage (V)	频率 Frequency (Hz)	电流 Current (A)	输入功率 Input Power (W)	转速 Speed (RPM)	风量 Air Flow		风压 Static Pressure (mmH₂O)	噪音 Noise (dB)-A
规格型号 Model No.	轴承 Bearing	电压 Voltage (V)	频率 Frequency (Hz)	电流 Current (A)	输入功率 Input Power (W)	转速 Speed (RPM)	(m³/min)	(CFM)	风压 Static Pressure (mmH₂O)	噪音 Noise (dB)-A
KFL8038HA1	Ball	115	50/60	0.15/0.13	14/12	2400/2850	0.68/0.88	24/31	3.30/4.83	31/35
KFL8038HA1	Sleeve	115	50/60	0.15/0.13	14/12	2400/2850	0.68/0.88	24/31	3.30/4.83	31/35
KFL8038HA2	Ball	220/240	50/60	0.08/0.07	14/12	2400/2850	0.68/0.88	24/31	3.30/4.83	31/35
KFL8038HA2	Sleeve	220/240	50/60	0.08/0.07	14/12	2400/2850	0.68/0.88	24/31	3.30/4.83	31/35
