原装正品 腾龙红外对应手动变焦 12VM412ASIR
红外对应手动变焦镜头
 | 可将Day/Night摄像机的性能限度发挥出来的支持IR(近红外)的镜头系列产品。采用特殊的光学设计,从可见光范围到近红外线范围,均以无焦点错位的、清晰敏锐的图像实现了真正的24小时监视功能。 |
 | 变焦镜头特性 |
 | 支持IR的镜头特性 |
| |
 | 丰富的镜头产品系列 | |
| 备有手动光圈、DC自动光圈和视频自动光圈等3种产品。您可以根据不同的用途,从丰富的产品系列中挑选出最合适的镜头。 |
| | |
| | |  | Mega-pixel(对应百万像素) |  | Aspherical Lens(非球面镜片) |  | Infrared (对应近红外线) |
12VM412ASIR
 | 产品规格 |
| 12VM412ASIR |
成像器大小 | 1/2 |
交换镜头座 | C |
焦距 | 4.0~12mm |
光圈范围 | 1.2~Close |
视场角 (水平x垂直) | 1/2型 | Wide | 93.7゜x68.9゜ |
Tele | 31.2゜x23.4゜ |
1/3型 | Wide | 68.9゜x51.1゜ |
Tele | 23.4゜x17.5゜ |
焦距范围 | 0.3m~∞ |
操作方法 | 焦点 | 手动 (带锁定结构) |
变焦 | 手动 (带锁定结构) |
光圈 | 手动 (带锁定结构) |
过滤器口径 | - |
后焦点 (in air) | Wide 10.157~Tele 19.911mm |
工作电压 | - |
质量 | 58g |
工作温度范围 | -20℃~+60℃ |
