10.0VA EI48-16.8系列灌封变压器、电源变压器
品牌/型号
ZETTLER/赛特勒/BV481S06100
产品特点：
1、真空环氧灌封，防潮、抗震
2、产品通过CE认证，安全保证，生产线全检
3、采用UL94V-0自熄灭阻燃材料
4、介电强度：4200Vrms
5、温度等级B级封胶
选型表（www.jenrui.com）：
| 次级保护 | 产品型号 | 输入电压(V) | 空载电压(V) | 输出电压(V) | 额定电流(mA) | 温度 | 额定功率(VA) | 认证 |
| 125 | BV481S06100 | 115 | 7.5 | 6 | 1667 | T 50 B | 10.0 | CE |
| 125 | BV481S09100 | 115 | 11.5 | 9 | 1111 | T 50 B | 10.0 | CE |
| 125 | BV481S10100 | 115 | 12.5 | 10 | 1000 | T 50 B | 10.0 | CE |
| 125 | BV481S12100 | 115 | 15 | 12 | 833 | T 50 B | 10.0 | CE |
| 125 | BV481S15100 | 115 | 18.8 | 15 | 667 | T 50 B | 10.0 | CE |
| 125 | BV481S18100 | 115 | 22.5 | 18 | 556 | T 50 B | 10.0 | CE |
| 125 | BV481S24100 | 115 | 30 | 24 | 417 | T 50 B | 10.0 | CE |
| 125 | BV481D06100 | 115 | 2×7.5 | 2×6 | 2×833 | T 50 B | 10.0 | CE |
| 125 | BV481D09100 | 115 | 2×11.5 | 2×9 | 2×556 | T 50 B | 10.0 | CE |
| 125 | BV481D10100 | 115 | 2×12.5 | 2×10 | 2×500 | T 50 B | 10.0 | CE |
| 125 | BV481D12100 | 115 | 2×15 | 2×12 | 2×417 | T 50 B | 10.0 | CE |
| 125 | BV481D15100 | 115 | 2×18.8 | 2×15 | 2×333 | T 50 B | 10.0 | CE |
| 125 | BV481D18100 | 115 | 2×22.5 | 2×18 | 2×278 | T 50 B | 10.0 | CE |
| 125 | BV481D24100 | 115 | 2×30 | 2×24 | 2×208 | T 50 B | 10.0 | CE |
| 63 | BV482S06100 | 230 | 7.5 | 6 | 1667 | T 50 B | 10.0 | CE |
| 63 | BV482S09100 | 230 | 11.5 | 9 | 1111 | T 50 B | 10.0 | CE |
| 63 | BV482S10100 | 230 | 12.5 | 10 | 1000 | T 50 B | 10.0 | CE |
| 63 | BV482S12100 | 230 | 15 | 12 | 833 | T 50 B | 10.0 | CE |
| 63 | BV482S15100 | 230 | 18.8 | 15 | 667 | T 50 B | 10.0 | CE |
| 63 | BV482S18100 | 230 | 22.5 | 18 | 556 | T 50 B | 10.0 | CE |
| 63 | BV482S24100 | 230 | 30 | 24 | 417 | T 50 B | 10.0 | CE |
| 63 | BV482D06100 | 230 | 2×7.5 | 2×6 | 2×833 | T 50 B | 10.0 | CE |
| 63 | BV482D09100 | 230 | 2×11.5 | 2×9 | 2×556 | T 50 B | 10.0 | CE |
| 63 | BV482D10100 | 230 | 2×12.5 | 2×10 | 2×500 | T 50 B | 10.0 | CE |
| 63 | BV482D12100 | 230 | 2×15 | 2×12 | 2×417 | T 50 B | 10.0 | CE |
| 63 | BV482D15100 | 230 | 2×18.8 | 2×15 | 2×333 | T 50 B | 10.0 | CE |
| 63 | BV482D18100 | 230 | 2×22.5 | 2×18 | 2×278 | T 50 B | 10.0 | CE |
| 63 | BV482D24100 | 230 | 2×30 | 2×24 | 2×208 | T 50 B | 10.0 | CE |
