乐清市强能电气有限公司是一家专业生产，销售配线器材的企业。拥有产品：电缆接头，电缆防水接头，电缆固定头，铜制电缆接头，金属电缆防水接头，金属电缆固定头，波纹管，防水浪管接头，闷盖，堵头，堵盖等。我们提供专业，周到的服务！全力提供技术支持！
现有权威产品认证：防水IP68等级~质量CE认证~材质SGS环保RoHS认证~橡胶PAHs认证~原材料无卤素认证~阻燃UL94V-2认证.
We provide "Professional, Quality and Service" for you.
A manufacturer of nylon cable gland, brass cable gland, plastic corrugated pipes & fittings, cable ties, cable glands, metal cable glands, wiring duct, cable clip, metal conduits & fittings, and Wiring Accessories...
Products quality has been approved by CE, RoHS, PAHs, and IP68 etc.
螺牙规格
Thread | 编号
Item.No. | 电缆范围
Cable Range
Ф(mm) | 螺纹外径
Thread O.D.
C1(mm) | 螺纹长度
Thread Length
C2(mm) | 扳手径
Spanner Size
A&F(mm) | 包装
Std.Pkg
(pcs) |
NPT1/4" | NCG-NPT1/4 -5.5 | 3-5.5 | 13.157 | 8.5 | 19 | 50 |
NCG-NPT1/4 -6.8 | 4-8 | 13.157 | 8.5 | 19 | 50 |
NPT3/8" | NCG-NPT3/8 -7 | 3-7 | 16.662 | 10 | 22 | 50 |
NCG-NPT3/8 -10 | 5-10 | 16.662 | 10 | 22 | 50 |
NPT1/2" | NCG-NPT1/2 -9 | 5-9 | 20.955 | 10 | 24 | 50 |
NCG-NPT1/2 -13 | 6-12.5 | 20.955 | 10 | 24 | 50 |
NPT3/4" | NCG-NPT3/4 -16 | 7-13 | 26.441 | 15 | 33 | 50 |
NCG-NPT3/4 -18 | 12.5-18 | 26.441 | 15 | 33 | 50 |
NPT1" | NCG-NPT1 -22 | 15-22 | 33.249 | 17 | 41 | 20 |
NCG-NPT1 -25 | 17-25 | 33.249 | 17 | 41 | 20 |
NPT1 1/4" | NCG-NPT11/4-25.5 | 17-25.5 | 41.91 | 17 | 52 | 20 |
NCG-NPT11/4-31 | 24-32 | 41.91 | 17 | 52 | 20 |
测试证明 适合户外使用的电缆固定头NPT1/2 穿线范围6-12mm ：
备注：1. 强能电气所有销售的电缆接头，全部包含标配的防水垫片。
2. NPT由于是堆牙螺纹，我们的标配是不带螺母的。客户如需配带六角螺母，请另外咨询我们。谢谢！
电话：0577-61679090 13732082345 李先生
QQ:153268116
选择强能，选择品质！
强能电气企业官网: Http://www.qne.cc
