Type | EPIC-GS525SZ |
CPU | ATOM D525 1.8G |
FSB | 533MHZ |
Chipset | Intel D525+NM10 |
Memory | DDRIII 1066/1333 MHz SDRAM ,MAX 4GB |
Graphics | On board GM3150 |
Audio | Integrated AL C662 Audio |
LAN | 2*Integrated RTL 8111DL 1000M |
Storage Interface | 1. 2*SATAll 2. 1*CF 3. MINI PCI-E |
IDE | 1*MINI IDE |
USB | 6*USB 2.0(2pcs on the back panel) |
BIOS | AMI BIOS |
Back Panel Connectors | 1. 1*PS/2 keyboard & Mouse port 2. VGA 3. 2*RJ-45 4. 2 USB PORT 5. 12V DC Input 6. AUDIO |
I/O Controller | 1. 2 USB PIN,Support 4 USB 2. 2 Fan Connector(CPU & system ) 3. 4*Serial PIN 4. 1*LVDS 24bit 5. 1*12PIN VGA |
Hardware Monitoring | 1. CPU/system power fan speed detection 2. CPU/system temperature detection 3. System voltage detection |
OS | Windows XP,Windows 2000,Linux,Win CE |
Operating Temperature | 0?~50?C |
Form Factor | MINI ITX 165x115mm |
