螺牙规格: 公制牙(Metric)、PG牙、G (PF / BSP / PS)牙、NPT牙。 ·产品材质: A.C.F部分以不锈钢制成，E部分以UL认可之尼龙PA66制成(防火等级UL94V-2),BD部分采用EPDM耐候橡胶制成。(可定制耐寒、耐高温橡胶;耐高酸碱、耐化学与抗腐蚀橡胶)。 ·工作温度: 静态-40℃至100℃,或瞬间可耐热至120℃;（可定制-60℃至220℃） ·产品特性: 特殊夹紧爪与夹紧圈之设计，夹紧电缆范围大，抗拉力特强，可防水、防尘、抗盐、耐弱酸、酒精、油、油脂及一般溶剂 | ||||||
| 编号 | 电缆范围 | 螺纹外径 | 螺纹长度 | 扳手径 | 包装 |
M8 x 1.25 | BCG-M8 -3.8 | 2-3.8 | 8 | 5.5 | 11/11 | 20 |
M10 x 1.5 | BCG-M10 -5.5 | 2-6.5 | 10 | 6.5 | 14/14 | 20 |
M12 x 1.5 | BCG-M12S-5.5 | 2-6.5 | 12 | 7 | 14/14 | 20 |
BCG-M12 -5.5 | 3-5.5 | 12 | 8 | 18/18 | 10 | |
BCG-M12 -7.8 | 4.5-8 | 12 | 8 | 18/18 | 10 | |
M16 x 1.5 | BCG-M16S-5.5 | 3-5.5 | 16 | 9 | 18/18 | 10 |
BCG-M16S-7.8 | 4.5-8 | 16 | 9 | 18/18 | 10 | |
BCG-M16 -7 | 4-7 | 16 | 9 | 22/22 | 10 | |
BCG-M16 -10 | 6-10 | 16 | 9 | 22/22 | 10 | |
M20 x 1.5 | BCG-M20S-8.8 | 4-8.8 | 20 | 9.5 | 24/24 | 10 |
BCG-M20S-12.5 | 7-12.5 | 20 | 9.5 | 24/24 | 10 | |
BCG-M20 -11 | 7-11 | 20 | 9.5 | 25/25 | 10 | |
BCG-M20 -14 | 9-14 | 20 | 9.5 | 25/25 | 10 | |
M25 x 1.5 | BCG-M25S-11 | 7-11 | 25 | 12 | 25/25 | 10 |
BCG-M25S-14 | 9-14 | 25 | 12 | 25/25 | 10 | |
BCG-M25 -16 | 12-16 | 25 | 12 | 30/30 | 10 | |
BCG-M25 -18 | 14-18 | 25 | 12 | 30/30 | 10 | |
M32 x 1.5 | BCG-M32 -22 | 16-22 | 32 | 12.5 | 40/40 | 10 |
BCG-M32 -25 | 18-25 | 32 | 12.5 | 40/40 | 10 | |
M40 x 1.5 | BCG-M40 -26 | 21-26 | 40 | 15 | 50/50 | 10 |
BCG-M40 -31 | 24-31 | 40 | 15 | 50/50 | 10 | |
M50 x 1.5 | BCG-M50 -33 | 25-33 | 50 | 15 | 59/59 | 10 |
BCG-M50 -41 | 31-41 | 50 | 15 | 59/59 | 10 | |
M63 x 1.5 | BCG-M63 -45 | 35-45 | 63 | 17 | 69/69 | 5 |
| 金属电缆防水接头PG型 Brass PG Thread Cable Glands | ||||||
| 编号 | 电缆范围 | 螺纹外径 | 螺纹长度 | 扳手径 | 包装 |
PG7 | BCG-PG7S-5.5 | 2-6.5 | 12.5 | 7 | 14/14 | 20 |
BCG-PG7 -5.5 | 3-5.5 | 12.5 | 8 | 18/18 | 10 | |
BCG-PG7 -7.8 | 4.5-8 | 12.5 | 8 | 18/18 | 10 | |
PG9 | BCG-PG9 -5.5 | 3-5.5 | 15.2 | 8 | 18/18 | 10 |
BCG-PG9 -7.8 | 4.5-8 | 15.2 | 8 | 18/18 | 10 | |
PG11 | BCG-PG11-7 | 4-7 | 18.6 | 9 | 22/22 | 10 |
BCG-PG11-10 | 6-10 | 18.6 | 9 | 22/22 | 10 | |
PG13.5 | BCG-PG13.5-8.8 | 4-8.8 | 20.4 | 9.5 | 24/24 | 10 |
BCG-PG13.5-12.5 | 7-12.5 | 20.4 | 9.5 | 24/24 | 10 | |
PG16 | BCG-PG16-11 | 7-11 | 22.5 | 9.5 | 25/25 | 10 |
BCG-PG16-14 | 9-14 | 22.5 | 9.5 | 25/25 | 10 | |
PG21 | BCG-PG21-16 | 12-16 | 28.3 | 12 | 30/30 | 10 |
BCG-PG21-18 | 14-18 | 28.3 | 12 | 30/30 | 10 | |
PG29 | BCG-PG29-22 | 16-22 | 37 | 12.5 | 40/40 | 10 |
BCG-PG29-25 | 18-25 | 37 | 12.5 | 40/40 | 10 | |
PG36 | BCG-PG36-26 | 21-26 | 47 | 15 | 50/50 | 10 |
BCG-PG36-31 | 24-31 | 47 | 15 | 50/50 | 10 | |
PG42 | BCG-PG42-33 | 25-33 | 54 | 15 | 59/59 | 10 |
BCG-PG42-41 | 31-41 | 54 | 15 | 59/59 | 10 | |
PG48 | BCG-PG48-45 | 35-45 | 59.3 | 17 | 69/69 | 5 |
