Features of the Products:
l Energy saved up to 70%. High intensity
l 5-years life span
l Special differrent view angles, mixing lighting design
l Instant start, no flickering, ni humming
l New inner high efficiency (95% ) With heat protection System, the constant current driver can work under Unstable voltage
l Special circuit design, each LED can work separately Thus it can avoid the influnence that a broken LED Cause
l No electric wave
l No such hazard that mercury of lead enters the Environment
l No RF interference
Applications:
Hotels
Conference/Meeting rooms
Factories & Offices
Commercial Purposes
Residential/Institution Buildings
Schools, Colleges & Universities
Hospitals
Places where energy saving and high color rendering index lighting are needed.
MAIN SPECIFICATIONS
NUMBER | ITEM | DESCRIPTION |
01 | Input | DC49V-70V |
02 | Power Consumption | 18W |
03 | Number of LED | 256 pcs SMD 3528 |
04 | Lumen of led beads | 1500-1800LM |
05 | Lumen of lamp | 1050-1250LM |
06 | Color | Neutral white |
07 | Color Temperature | 2800-8000K |
08 | Color Rendering Index | >70 |
09 | Life time | >50,000hours |
10 | Operating Temperature | -20℃ to +60℃ |
11 | Storage temperature | -20℃ to +60℃ |
12 | Humidity Operating | 10-90% |
13 | Humidity Storage | 10-90% |
14 | Brightness | 1meter:456Lux; 2meter:114.01Lux; 3meter:50.66Lux |
15 | Certifications | CE RoHs |
16 | Weight | Gross Weight:1940g Wet Weight :1670g |
17 | Size | 300mm*300mm;Thickness:15mm |
LED DRIVER DATA
Input power | <22W |
Input Voltage | AC85-265V |
Rated Voltage | DC49V-70V |
Rated Currency | 320mA |
Efficiency | 85% |
LED Lumen Attenuation:
Operating time(hours ) | Lumen decrease(% ) |
5,000 | 2 |
10,000 | 5 |
20,000 | 11 |
50,000 | 24 |
