| 等级 GRADE | AU-1101 |
| 特性及用途 CHARACTERISTICS APPLICATION | 适用于PCB业钻孔子用垫板SUITABLE FOR PCB/PWB DRILLING OPERATION BACK BOARD |
| 树脂种类型 RESIN | 酚醛树脂 PHENOLIC RESIN |
| 基材 COMPOSITION | 绝缘纸-木浆纸 INSULATING PAPER-BLEACHED KRAFT PAPER |
| 厚度 （MM） THICKNESS | 3．0-50 |
| 尺寸 （MM） STANDARD SHEET SIZE | 1020*1020 |
| 适合加工性 FABRICATING SUITABILITY | 锯或钻孔 SAWING OR DRILLING |
| 色彩 COLOR | 橙色 ORANGER |
| 比重 SPECIFIC GRAVIT | 1.45-1.5 |
| 耐燃等级 FLAME CLASSIFICATION | UL 94 | 94HB |
| 质层耐电压 DJELECTRICDREAKDO WN STRENGTHS | C-90/20/65 | >10 KV/MM |
| 绝缘电阻 INSULATION RESISTANCE | C-90/20/65 | 1*1010~1*1012Ω |
| 硬度HARDNESS（SHORED TRPE/HRR） | | 88~90 /121~123HRR |
| 耐热性 HEAT RESISTANCE | A | 180 MIN*130℃ GOOD |
| 弯曲度 WARP | A | <0.5% |
| 吸水率 WATER ABSORPTION | C-24/25+D-24/23 | 0.6~0.9% |
| 存放方式 STORAGE 室温下储存30天 | 20~30℃/65% RH/LEVEL/SEAL UP FOR PACKAGE |
