注1：在温度为40℃，风扇在额定电压下连续运转30分钟后，测得的功率、电流和转速。
注2：在背景噪音在10±1dBA，风扇正常运转的情况下，麦克风距离风扇1m时测得的噪音大小

Manufacturer: EBM PAPST Order Code: 9599908 Manufacturer Part No: W2S130-AA03-01

RoHS Compliance:Yes

• FAN, 160MM, 240VAC
• External Height:55mm
• External Depth:55mm
• External Diameter:150mm
• Current Type:AC
• Supply Voltage:240VAC
• Flow Rate:97l/s
• Noise Figure Typ:49dB
• Bearing Type:Ball
• Power Connection Type:Lead
• Series:W2S130
• SVHC:No SVHC (15-Dec-2010)
• Approval Bodies:UL, VDE, CSA
• Bearing Type:BB
• Depth:55mm
• External Length / Height:55mm
• Fixing Centres:162mm
• Fixing Hole Diameter:4.5mm
• Flow Rate Imperial:206cu.ft/min
• Flow Rate Metric:350m³/h
• Lead Length:330mm
• Operating Temperature Max:65°C
• Operating Temperature Min:-30°C
• Outer Diameter:150mm
• Power Consumption:40W
• Voltage Rating VAC:240V
• Operating Lifetime:50000h
• Panel Cutout Diameter:147mm
• Supply Voltage VAC:240VAC
