| Measuring Meth | Absolute |
| Measuring standard | DIADUR glass scale with absolute track and incremental track |
| Thermal expansion coefficient | αtherm≈ 8 x 10-6K-1 |
| Accuracy grade | |
| Measuring lengths (ML) in mm | |
| Absolute position values | EnDat 2.1 |
| Calculation time tcal | < 1 ms |
| Incremental signals | 1 VSS |
| Signal period | 20 µm |
| Cutoff frequency -3dB | ≥ 150 kHz |
| Power supply | 5 V ± 5 % at linear encoder/< 300 mA (without load)
(power supply possible via Remote Sense) |
| Electrical connection | Sep. adapter cable (1 m/3 m/6 m/9 m) connectable to mounting block |
| Max. cable length | Upon request |
| Max. traversing speed | 180 m/min |
| Required moving force | ≤ 4 N |
| Vibration (55 to 2000 Hz) | ≤ 200 m/s² (EN 60068-2-6) |
| Shock (11 ms) | ≤ 300 m/s² (EN 60068-2-27) |
| Acceleration | ≤ 100 m/s² in measuring direction |
| Operating temperature | 0 to 50 °C |
| Protection (IEC 60529) | IP 53 when installed according to the mounting instructions
IP 64 if compressed air is connected |
| Weight | 0.4 kg + 3.3 kg/m measuring length |
