【芯龙一级代理 XL1509 AP1509 TD1509 IC DC/DC 2A/40V PWM】价格_厂家

品牌/型号

芯龙原装/XL1509各电压

类型

电源模块

功率

15

批号

12+

型号

XL1509各电压

封装

SOP8

品牌

芯龙原装

Features                                               General Description
Wide 4.5V to 40V Input Voltage Range                  The   XL1509   is   a   150   KHz   fixed   frequency
3.3V,5V,12V, and adjustable versions                  PWM      buck   (step-down)    DC/DC     converter,
Output Adjustable from 1.23V to 37V                   capable     of driving   a 2A   load with   high
Maximum Duty Cycle 100%                               efficiency,   low   ripple   and   excellent   line   and
Minimum Drop Out 1.5V                                 load     regulation.    Requiring    a   minimum
Fixed 150KHz Switching Frequency                      number of external components, the regulator
2A Constant Output Current Capability                 is    simple    to use    and   include    internal
Internal Optimize Power Transistor                    frequency          compensation         and        a
High efficiency                                       fixed-frequency oscillator.
Excellent line and load regulation
TTL shutdown capability
                                                       The PWM control circuit is able to adjust the
ON/OFF pin with hysteresis function
Built in thermal shutdown function                    duty ratio linearly from 0 to 100%. An enable
Built in current limit function                       function,   an   over   current   protection   function
                                                       is   built inside. When   second    current limit
Built in second current limit function
Available in SOIC8 package                            function    happens,    the operation   frequency
                                                       will be reduced from 150KHz to 50KHz. An
                                                       internal   compensation     block   is built in to
                                                       minimize external component count.
Applications
LCD Monitor and LCD TV
Digital Photo Frame
Set-up Box
ADSL Modem
Telecom / Networking Equipment
