System

Processor

Intel ® ATOM™ D525  1.8GHz

Chipset

Intel® ICH8M

Memory

1 X DDR3 1066/1333MHz DIMM,up to 4GB

Storage

Serial ATA

2.5〞5400rpm 320G

I/O Interface

PS/2

1 x PS/2

USB

4x USB2.0

LED

1 x Power Button With LED

WIFI Antenna

1 x Antenna

Audio

1 x Mic-in / 1 x Line-out

Serial Port

4 x COM (RS232)

LPT

1 x LPT

DC JACK

1 x DC JACK

Display

Dual Display

DVI+VGA

Ethernet

Chipset

2xRTL8111E

Speed

2 x 1000Mbps

Connector

2 x RJ45

WIFI

802.11b/g/n

Mechanical and Environmental

Dimensions

285mm (L) x 200mm (W) x 52mm (H)

Reliability

MTBF≥50000h; MTTR≤0.5h

Operating Temperature

0℃~40℃

Storage Temperature

-20℃~70℃

Operating Humidity

5% ~ 90% (non-condensing)

Power

Power Supply

DC 12V/5A

Operating System

OS

Windows XP/Windows 7/ Linux
