【DB12N4-S东日扭力扳手,TOHNICHI东日表盘式扳手DB12N4-S】价格_厂家

DB12N4-S东日扭力扳手,TOHNICHI东日表盘式扳手DB12N4-S

1台起批

￥1300.00

深圳市深圳市宝安区龙华民治民乐工业园

产品属性

图文详情

品牌推荐

品牌/型号

TOHNICHI/东日/DB12N4-S

特性

普通

品牌

TOHNICHI/东日

材质

45#钢

制式

英制

型号

DB12N4-S

表面处理

镀铬

重量

0.4（g）kg

TOHNICHI日本东日扭力扳手，表盘式扭力扳手DB1.5N4-S,DB3N4-S,DB6N4-S,DB12N4-S,DB25N-S,DB50N-S,DB100N-S,DB200N-S,DB280N-S,DB420N-S,DBE56ON,DBE700N,DBE850N,DBE1000N4,15DB4-S,30DB4-S,60DB4-S,120DB4-S,230DB3-S,450DB3-S,900DB3-S,900DB3-S,1800DB3-S,2800DB3-S,4200DB2-S,5600DBE2-S,7000DBE2-S,8500DBE2-S,10000DBE2-S

产品详细参数如下:

Model			Torque Range						Hforce at Max.Torque		Effective Lgth.		Overall Lgth.		Square Drive		Weight approx.
Model			Min.-Max.			Graduation			Hforce at Max.Torque		Effective Lgth.		Overall Lgth.		Square Drive		Weight approx.
S.I.	Metric	American	S.I.	Metric	American	S.I.	Metric	American	N	lb.	mm	in.	mm	in.	mm	in.	kg	lb.
DB1.5N-S	15DB3-S	DB13I-2AS	N.m 0.2-1.5	kgf.cm 2-15	in.lbs 0-13	N.m 0.02	kgf.cm 0.2	in.lbs 0.2	8.3	1 27/32	180	7 3/32	230	8 7/8	6.3	1/4	0.4	21/32
DB3N-S	30DB3-S	DB26I-2AS	0.3-3	3-30	0-26	0.05	0.5	0.5	16.7	3 41/64				8 7/8				21/32
DB6N-S	60DB3-S	DB40I-2AS	0.6-6	6-60	0-40	0.1	1	0.5	33.3	5 41/64				9 1/16				7/8
DB12N-S	120DB3-S	DB75I-2AS	1-12	10-120	0-75	0.2	2	1	66.7	10 37/64				9 1/16
DB25N-S	230DB3-S	DB150I-3AS	3-25	30-230	0-150	0.5	5	2	125	19 3/64	200	7 7/8	245	9 21/32	9.53	3/8
DB50N-S	450DB3-S	DB300I-3AS	5-50	50-450	0-300	0.5	5	5	208	31 25/32	240	9 7/16	320	12 19/32	9.53		0.6	1 11/32
-	-	DB600I-3AS	-	-	0-600	-	-	10	-	49 15/64	-	12 3/16	-	15 3/4	-		-
DB100N-S	900DB3-S	DB600I-4AS	10-100	100-900	0-600	1	10	10	323	49 15/64	310	12 3/16	400	15 3/4	12.7	1/2	0.7	1 9/16
-	-	DB25F-3AS	-	-	ft.lbs 0-25	-	-	ft.lbs 0.5	-	31 25/32	-	9 7/16	-	12 19/32	-	3/8	-	1 11/32
		DB50F-3AS			0-50					49 15/64		12 3/16		15 3/4		3/8		1 9/16
		DB50F-4AS			0-50					49 15/64		12 3/16		15 3/4		1/2		1 9/16
DB200N-S	1800DB3-S	DB100F-4AS	20-200	200-1800	0-100	2	20	1	488	74 13/32	410	16 1/8	500	19 11/16	12.7	1/2	1	1 7/32
DB280N-S	2800DB3-S	-	30-280	kgf.m 3-28	-	5	kgf.m 0.5	-	467	-	600	-	690		19.05	-	1.65	-
-	-	DB175F-4AS	-	-	0-175	-	-	2	-	130 15/64	-	16 1/8	-	19 11/16	-	1/2	-	1 7/32
DB420N-S	4200DB2-S	DB250F-6AS	40-420	4-42	0-250	5	0.5	5	525	126 63/64	800	23 5/8	890	27 5/32	19.05	3/4	2.5	3 41/64
DBE560N-S	5600DBE2-S	DB350F-6AS	50-560	5-56	0-350	5	0.5	5	560	133 11/32	1000	31 1/2	1100	35 1/32			4	5 17/32
DBE700N-S	7000DBE2-S	DB500F-6AS	70-700	7-70	0-500	10	1	10	609	132 1/2	1150	45 9/32	1260	49 5/8			5.5	12 1/8
DBE850N-S	8500DBE2-S	-	100-850	10-85	-			-	680	-	1250	-	1360		25.4		6.1	-
DBE1000N-S	10000DBE2-S	DB800F-8AS	100-1000	10-100	0-800			10	741	180 19/32	1350	53 5/32	1490	58 21/32		1	6.4	14 1/8
DBE1400N-S	14000DBE2-S	DB1000F-8AS	200-1400	20-140	0-1000	20	2	10	875	190 15/32	1600	63	1740	68 1/2			8.6	18 31/32
DBE2100N-S	21000DBE2-S	DB1500F-8AS	200-2100	20-210	0-1500	20	2	20	1050	228 9/16	2000	78 3/4	2140	84 1/4			12.8	28 7/32
DBE2800N-S	28000DBE2-S	DB2000F-12AS	300-2800	30-280	0-2000	50	5	20	1250	507 15/16	2240	47 1/4	2380	50 19/32	38.1	1 1/2	16.8	54 1/32
DBR4500N-S	45000DBR-S	DB3000F-12AS	500-4500	50-450	0-3000			50	3750	609 33/64	1200	59 1/16	1285	62 13/32	38.1	1 1/2	24.5	56 7/32
DBR6000N-S	60000DBR-S	-	600-6000
