额定电流 : 3A AC,DC

额定电压 : 250V AC,DC

工作温度 : -25 deg C ~+85 deg C

接触电阻 : 20m Omega Max.

绝缘电阻 : 800M Omega Min.

耐压值 : 500V AC/minute

SCT2545H- XXP

规格:04P.

材质:PA66 UL94V-0

包装:1000pcs/包

SCT2545T

厚度:0.20mm

材质:磷青铜

表面处理：镀锡

适用线型:AWG#20#26(OD:1.9mm)

包装:10,000pcs/卷

SCT2545WV/WR-XXP

规格:04P

绝缘体材质:PA66 UL94V-0

接触体材质:黄铜,镀锡

包装:1000pcs/包

~~~~~~~~~~~~~~ ~~~~~~~~ ~~~~~~~~ ~~~~~~~~ ~~~~~~~~ ~~~~~~~~ ~~~~~~~~ ~~~~~~~~ ~~~~~~~~ ~~~~~~~~ ~~~~~~~~ ~~~~~~~~ ~~~~~~~~ ~
