SCT3002 Series  (Molex43640/43645-Pitch3.0  Wire to Board Connector )
Specifications :
Current Rating : 5A AC,DC
Voltage Rating : 250V AC,DC
Temperature Range : -25deg C ~+85 deg C
Contact Resistance : 10m Omega Max.
Insulation Resistance : 1000M Omega Min.
Withstanding Voltage :1500V AC/minute
*Contact SCT3002 for detals*

Housing
Part No:SCT3002MH/FH-
Poles:1*2P-1*12P.
Material:Nylon66 UL94V2
Packing Q'TY:1000pcs/bag
Mates With SCT3001FT/MT  Series Terminal

Terminal
Part No:SCT3001FT/MT
Thickness:0.20mm
Material:Phosphor bronze
Finish:Tin Plated
Wire Range:AWG#22-#28
Insulation O.D. : 1.3mm ( Max.)
Q'TY:10,000pcs/reel
Mates With SCT3002MH/FH- Series Single row Housing

Wafer (DIP  Type)
Part No:SCT3002WV/WR-
Poles:1*2P-1*12P.
Material:Nylon66 UL94V2
Packing Q'TY:1000pcs/box
Mates With SCT3002MH/FH-   Series Single  Housing
