功能用途Functions
可在平面或异型立体、曲面等承印物表面，实现全彩色图文转印，无需套色，图像清晰美观，色彩鲜艳，历久弥新。
适用于标识标牌、广告制作、图文影像、建筑装饰的表面印花等。
适用材料范围：珠光、拉丝等系列预涂金属板材及各种预涂金属型材，预处理的石材、陶瓷、玻璃、木材等。
Can be transferred in the plane and fully solveprinting processingof all kinds of shaped, curved, three-dimensional surface.Once completed withoutchromatography,saving time and work and increasing madrket competitiveness.
Can be widely used in building decoration,wedding photo studio,advertising,logo signs,gifts and other industries.
Range of applicable materials:pearl,drawing and other pre-coated metal plates and a variety of pre-coated metal sheet profiles,pretreatment of stone,ceramic glass,wood and so on.
主要技术参数Main technical parameters
1、输入电压：220V/380V/50HZ
2、总功率：3.5KW
3、温度范围：0～399℃
4、预热时间：15～30min
5、真空压力：－0.1KPa
6、外形尺寸：1250×2160×1350
7、工作面积：400×600mm
8、整机重量：130㎏
1, Input voltage: 220V/380V/50HZ
2, the total power: 3.5KW
3, temperature range: 0 ~ 399℃
4, the warm-up time: 15 ~ 30min
5, vacuum pressure:-0.1KPa
6, external dimensions:1250×2160×1350
7, the working area: 400× 600mm
8, Weight:130㎏
性能特点Features
1、整机按照人体工程学设计，德国西门子PLC微电脑开关控制，操作简单方便。
2、低压步进电机，日本THK高精度直线导轨， 精密滚珠丝杠配合转动。单轴数控系统操作，运行平稳，经久耐用。
3、低音高效的真空系统结合高弹力真空膜，切实实现极限真空，使工件与转印膜密切贴合。保证逼真完美的转印效果。
4、整机控制电路全部采用航空快速接头插接式设计，方便快捷。
5、机器主体与机架为分体式组合设计，便于检测维修维护。
6、敞开式设计，可方便客户在远程指导下进行简单维修操作。
1, The whole machine is designed in ordance with human engineering,micro switch Siemens PLC control, easy operation.
2, Low-voltage stepper motors, Japan THK’s high precision guide linear, precision ball screw with the rotation. Single-axis CNC system operation, smooth running durable.
3, Bass and efficient vacuum system combined with high elastic membrane, realizing the limit of vacuum, so the workpiece can fit with the transfer film closely to ensure a perfect transfer realistic effect.
4, The machine control circuit use all air quick coupling plug design, convenient and quick.
5, The machine body and frame are combination designs of fission type,covinient to be repaired and maintenaned.
6, Open design to facilitate customers simple remote maintenance operations under the guidance of remote guidance.
