该线是槽铝式中空玻璃生产的专用设备，主要包括：立式玻璃清洗机、覆片机、辊压机、翻转台，可完成中空玻璃的清洗干燥、铝框定位、覆片、辊压合片、翻转移出等工序，该线采用倾斜立式结构，占地面积小，操作方便。
【技术参数】
设备型号 GPLG-XY1800
输入电源 380V 50Hz
输入功率 17.5Kw
加工尺寸 1800×2500mm
最小加工尺寸 280×400mm
原片玻璃厚度 3~18mm
传送速度 8~15m/min
外形尺寸 17500×2350×3000mm
This machine is the equipment for hollow glass mainly includes: vertical glass cleaner, layer covering machine, roller press and roll over table. It can finish the processes like washing & drying, positioning the aluminum frame, layer covering, rolling and rolling over of the hollow glass. This line is vertical structure, covering a small area. It is easy to operate.
Technical Parameter：
Model GPLG-XY1800
Input voltage 380V 50Hz
Input power 17.5Kw
Max. glass size 1800×2500mm
Min. glass size 280×400mm
Glass thickness 3~18mm
Working speed 8~15m/min
Overall dimension 17500×2350×3000mm
该线是槽铝式中空玻璃生产的专用设备，主要包括：立式玻璃清洗机、覆片机、辊压机、翻转台，可完成中空玻璃的清洗干燥、铝框定位、覆片、辊压合片、翻转移出等工序，该线采用倾斜立式结构，占地面积小，操作方便。
【技术参数】
设备型号 GPLG-XY1800
输入电源 380V 50Hz
输入功率 17.5Kw
加工尺寸 1800×2500mm
最小加工尺寸 280×400mm
原片玻璃厚度 3~18mm
传送速度 8~15m/min
外形尺寸 17500×2350×3000mm
This machine is the equipment for hollow glass mainly includes: vertical glass cleaner, layer covering machine, roller press and roll over table. It can finish the processes like washing & drying, positioning the aluminum frame, layer covering, rolling and rolling over of the hollow glass. This line is vertical structure, covering a small area. It is easy to operate.
Technical Parameter：
Model GPLG-XY1800
Input voltage 380V 50Hz
Input power 17.5Kw
Max. glass size 1800×2500mm
Min. glass size 280×400mm
Glass thickness 3~18mm
Working speed 8~15m/min
Overall dimension 17500×2350×3000mm
