10A 125 / 250VAC (UL/CUL)

10(4)A 250V~μT85 (FIMKO, ENEC)

Initial contact resistance : 20m ohm max.

Insulation resistance : 100M ohm  min, at 500VDC

Dielectric strength : 1,000 VAC for 1 minute

Electrical life : 6,000 cycles

Temperature range : -20 to + 85 degrees in Celsius

Base : Nylon 66, 94V-2 min.

Actuator : Nylon 66, 94V-2 min.

Spring : Steel wire

Contact arm : Silver plated alloy

Terminals : Silver plated copper alloy
