技术参数：

水平钻的钻孔直径：       Max.drilling dia lfhorizontal drill         max=35mm   d=13mm（多钻头时）

垂直钻钻孔深度：          Max.drilling depth of vertical drill       Hmax=60mm

加工长度：                   Max.processingt length                     1850mm

最小加工长度：                    Min.processingt length                     130mm

钻轴总数：                         Totao number lf spindes                    11*4+22*1位

钻接头装配孔径：                Installation dia of drill bit shet          10mm

电机总功率：                      Total power                                       5.9kw

主轴转速：                         Spindle speed                                   2840rpm

外形尺寸：                         Overall dimension                            2800*3000*1500mm

机器重量：                         Weight of  machine                           1100kg
