技术参数：

水平钻钻孔直径 Max.drilling dia.of horizontal drill                       Max=35mm(单排钻）      d=13mm（多排钻时）

                                                                                                          For single drill                 For single drill

垂直钻钻孔深度 Max.drilling depth of vertical drill                               60mm

加工长度          Max.processing length                                               2500mm

最小加工长度          Min.prouessing length                                               250mm

钻轴总数                Total number of spindles                                          22*2+11*8位

钻接头装配孔径       lnstallation dia.of drill bit shaft                                 10mm

电机总功率            Total power                                                                 11.8kw

主轴转速                Spndle speed                                                              2840rpm

外形尺寸                Overall dimension                                                      5200×3000×1620mm

机器重量                Weight of machine                                                      2310kg
