技术参数：

水平钻钻孔直径                 Max=35mm(单钻头）  d=13mm（多钻头时）

Max.drilling dia.ofhoyizontal drill                  For sing drill                            For single drill

垂直钻钻孔深度                  80mm

Max.drilling depth of vertical drill

加工长度                          1250mm

Max.processing length

最小加工长度                          70mm

Min processing length

转轴总数                               14位

Total number of spindles

钻接头装配孔径                       12.7mm

lnstallation dia.of drill bit shaft

电机总功率                            8.9kw

Total power

主轴转速                               4500rpm

Spindle speed

外形尺寸                               2100×1200×1600mm

Overall dimension

机械重量                              1900kg

Weight of machine
