君沛亮电子高低位双排升降式接线端子VV-9.52mm
| 安规类别/Safety category: | cULus |
| 额定电压/Voltage rating: | 300V |
| 额定电流/Current rating: | 30A |
| 适用线经/Wire range: | |
| 单芯线经（AWG）/Solid wire(AWG): | 10-30 |
| 多芯线经（AWG）/Stranded wire(AWG): | 10-30 |
| 最大锁紧扭力/Torque: | 5.2Lb-In |
| 螺丝规格/Screw: | M3.5 |
| 剥线长度/Wire strip length: | 10~11mm |
| 耐电压值（1分钟）/Withstanding Voltage: | 1.6KV |
| 安全认证/Safety Approval: |  |
| 操作温度/Operating temperature: | -40℃ to +115℃ |
| 焊锡温度/Soldering temperature: | 250℃ ±10℃ /5Sec |
