Product features
	Sensing range min ... max:	0.01 m ... 13.5 m
	Relating to:	Reflector PL80A
	Light source:	LED
	Type of light:	visible red light
	Light spot diameter:	Approx. 400 mm at 8 m distance

Technical data
	Design:	cuboid
	Dimensions (W x H x D):	20 mm x 60 mm x 43 mm
	Angle of dispersion:	ca. 2.5 °
	Supply voltage min ... max:	AC/DC 24 ... 240 V / 12 ... 240 V
	Switching output voltage:	Relay 1 x c/o, electrically isolated
	Switching output:	Light switching
	Power consumption:	<= 2 VA
	Switching current max.:	3 A / 240 V AC; 3 A / 30 V DC
	Response time:	<= 15 ms
	Switching frequency:	33 Hz
	Connection type:	cable, 2 m
	Cable material:	PVC
	Cable diameter:	Ø 6.3 mm
	Number of cores:	5
	Conductor cross section:	0.76 mm²
	Circuit protection:	VSconnections reverse-polarity protected / Interference suppression
	Enclosure rating:	IP 67
	Ambient operation temperature, min ... max:	-25 °C ... +55 °C
	Ambient storage temperature, min ... max:	-40 °C ... +70 °C
	Weight:	ca. 160 g
	Front screen heating:	-
	Polarisation filter:	√
	Housing material:	ABS
