【TPC-1750H 研华科技平板电脑】价格_厂家

品牌/型号

Advantech/研华/TPC-1750H

外形尺寸

45（mm）mm

型号

TPC-1750H

品牌

Advantech/研华

质保

一年（年）

17" SXGA TFT LED LCD Intel® Atom™ Thin Client Terminals

Main Features

TPC-1750H-N2BE

Environment	Humidity	10 ~ 95% RH @ 40° C, non-condensing
	Ingress Protection	Front panel: IP65
	Operating Temperature	0 ~ 45° C (32 ~ 113° F)
	Storage Temperature	-20 ~ 60°C (-4 ~ 140°F)
	Vibration Protection	2 Grms (5 ~ 500 Hz)
General	BIOS	Award® 4 MB
	Certifications	BSMI, , CE, Class A, UL
	Cooling System	Fanless design
	Dimensions (W x H x D)	413.7 x 347.2 x 63.8 (16.28" x 13.68" x 2.5")
	Enclosure	Die-cast aluminum alloy Back housing:
	Mounting	Desktop, Wall or Panel Mount
	OS Support	Microsoft® Windows® 7/XPE/WES, Windows CE 5.0/6.0 with Java Script, Linux with Firefox explorer and Java Script plugin
	Power Consumption	35 W (typical)
	Power Input	18 ~ 32 VDC
	Watchdog Timer	1 ~ 255 sec (system)
	Weight (Net)	3.5 kg (7.71 lb)
LCD Display	Backlight Life (hrs)	50,000
	Contrast Ratio	1000:1
	Display Size	17"
	Display Type	SXGA TFT LED LCD
	Luminance (cd/m2)	350
	Max. Colors	262 K
	Max. Resolution	1280x1024
	Viewing Angle (H/V°)	170/160
System Hardware	Chipset	Intel® 945GSE+ICH7M
	CPU	Intel® Atom™ N270 1.6 GHz
	I/O	RS-232 x1, RS-232/422/485 x 1, USB 2.0 x 2 (Host)
	LAN	10/100/1000Base-T x 2
	Memory	2GB SO-DIMM DDR2 667 SDRAM
	Storage	CFast slot x 1, Optional, external 2.5" SATA HDD kit
Touchscreen	Lifespan	10 million touches at single point
	Light Transmission	Above 75%
	Type	5-wire, analog resistive
