1).Bluetooth Version:2.0+EDR Class II

2).Supports Bluetooth hands-free ,headset   profiles
3)patibility:mostofbluetooth mobile phone
4).Talking time:up to 4hours

5).Standby time:up 100 60hours
6).Charging  time:within 3 hours

Bluetooth Headset Using Instruction

• Charge the Headset

Charge H508 for 2Hours

1. Insert the charger to the bottom of Headset,the red indicator which need take one minute at most will be on as charging.After finishing charging which will take about 2hours the red indicator will turn off.
2. Disconnect the charger with headset

• Activate Bluetooth function in Mobile

The bluetooth function in mobile presets as “Shut 0ff”.Before using headset,please activate the function in your mobile.

Generally the steps as following:

1. Selecting(Menu)>>Setting>>Connecting>>Bluetooth Link>>Setting
2. Roll on to Bluetooth On/Off
3. Press “Change”
4. Press “Select”.If bluetooth on it’ll keep working till you turn it off.

• Pair your Mobile with Bluetooth headset

Step A –Put headset under Pairing Status,before using headset,please pair it with your mobile:Hold the answer key for 3seconds till the blue LED on.The bluetooth will be found by other bluetooth devices.

Step B –Set in mobile making it find headset

1. For mostly mobile:Selecting(Menu)>>Setting>>Connect>>Bluetooth Link>>Handsfree>>Searching devices,mobile will list all the bluetooth devices it found.
2. Choosing H508
3. Press for confirmation to pair handsfree mobile.
4. Input passkey:0000
5. Press “ok” to confirm.

Once the pair is essful,the blue LED will flash.

• Test/Use

Now,mobile and headset complete pairing,you can use it to dial or answer any call.

1. Wear bluetooth headset
2. Dial the number in your mobile and press”Send”
3. If the pair is essful,you will hear the ringing.After this essful pairing,no need repeat the aboved steps of setting if you use again in future.

• Direction for Functions

Power on and Power off

Turn on the headset,press red “answer”key till LED flash,then release it.

Turn off the headset,Press and hold “nswer”key till LED flash rapidly.

For saving power,lease turn off your headset if not using for a long time.

Volume adjust

1. The headset is preset at the highest volume.
2. Please adjust it in your mobile to reach a ideal effection.

Making a conversation

Function               Operation

End a call             Tap “answer”key

Answer a call           Tap “answer”key

Redial last call           double tap”answer”key

Indicator(offer the information for headset status)

         Insert charger

Indicator                 Status

Red LED on               Charging

Red LED off               complete charging

         Without charger

Indicator                   Status

Off                         Off

On(Blue LED)               Pairing

Indicator(Offering information for headset status)

 Tones reminder
