项目ltem

特性Performance Characteristics

使用温度范围

Operating Temperature Range

-40to+105℃

-25to+105℃

额定电压范围

Rated Voltage Range

6.3to100VDC

160to450VDC

电容量范围

CapacitanceRange

0.1to4700μF

0.47to220μF

电容量允差

Capacitance Tolerance

+20%（100Hz or 120Hz，+20℃）

漏电流Leakage Current

（+20℃，最大max）

I≤0.03CV或4（μA）额定工作电压充电3分钟后读数，取大者               I≤0.01CV or 3(μA)After3minutes,whichever is greater measured with rated working voltage applied

I≤0.03CV+10（μA）额定工作电压充电3分钟后读数，

取大者                I≤0.03CV+10(μA)After

3minutes,whichever is greater measured with rated working voltage applied

损耗角正切值

Dissipation Factor

（tgδ）

容量>1000μF时，每增加1000μF D.F值增加2%( 100Hz or 120Hz，+20℃)

For capacitance1000μF,Add 2%per another 1000μF (100Hz or 120Hz，+20℃)

低温特性

Low Temperature

Characteristics

（120Hz）

阻抗比，最大max Impedance ratio at 120HZ to the 20℃value

高温负荷寿命Load Life

After 1,000 hours application of rated voltage at 105℃,capacitors meet the characteristics

Meet the characteristics requirements mentioned below

环境温度:+105℃

Ambient timperature: +105℃

施加电压:额定工作电压(VDC)

Applied voltage: Rated Working Voltage(DVC)

试验后要求:室温下恢复16小时,+20℃测试

After test requirements: Resumde 16 hours at

normal temperature

电容量变化:≤25%规定值

Capacitance change:≤25% of the initial measured value

损耗角正切值:≤200%初始值

Dissipation Factor:≤200% of the initial specified value

漏电流:≤规定值

Leakage Current:≤The initial specified value

高温无负荷寿命Shelt Life

试验条件

Test conditions

持续时间:500小时

Duration time: 500hours

环境温度:+105℃

Ambient temperature:+105℃

施加电压:无

Applied voltage: None

试验后要求:室温下恢复16小时,+20℃测试

After test requirements: Resumed 16 hours at

normal timperature

电容量变化:≤25%规定值

Capacitance change:≤25% of the initial measured value

损耗角正切值:≤200%初始值

Dissipation Factor:≤200% of the initial specified value

漏电流:≤200%规定值

Leakage Current:≤200% of the initial specified value
