启盛主推款 9.6MM×5电磁式侧发音蜂鸣器 无源 插针1.5v 3v 5v
Model No | QSM-09B |
Rated Voltager | 1.5V |
Operating Voltage | 1～2V |
Max.Rated Current | 80mA |
Coil Resistance(DC) | 5.5±1Ω |
Coil Impedance(AC) | 9.5±3Ω |
Min.Sound Pressure Level | 85dB/10cm |
Resonant Frequency | 2731Hz |
Operating Temperature | -20℃~+70℃ |
Weight | 1g |
