Approval	VDE, CSA, UL, CE
Bearing	Ball bearings
Connection line	Single strands AWG 24, TR 64, bared and tin-plated.
Dimensions	119 x 119 x 25 mm
Direction of air flow	Air exhaust over bars
Direction of protection	Left, looking at rotor
General description	Open loop speed control on request. Electronic commutation completely integrated.
Housing material	Fiberglass-reinforced PBT plastic
Lifetime L10 at 40 °C	70000 h
Lifetime L10 at maximum temperature	30000 h
Locked-rotor protection	Blocking and overload protection
Mass	0.175 kg
Material of impeller	Fiberglass-reinforced PA plastic
Motor protection	Protected against reverse polarity and locking.
Option	Speed signal
