型号 Item
規 格 Specifications
YH-1600
YH-2550
噴頭部分Print Resolution
微壓電式噴頭(180 噴嘴 x 8排) x 1個Piezo Technology 、 Epson DX5 Print-head 、180nozzles x 8lines
最大噴畫範圍Maximum Print/Cut Width
1600 mm
2500mm
解析度Print Resolution
540 dpi, 720 dpi, 1440 dpi
噴畫模式Print Mode
540 x 720dpi
720 x 720dpi ,720 x 1080dpi
720 x 1440dpi , 1440 x 1440dpi
打印精度Print Resolution
草稿(3pass)20㎡/ H
草稿(2pass)22㎡/ H
文字(4pass)18㎡/ H
文字(4pass)20㎡/ H
图像(6pass)15㎡/ H
图像(6pass)17㎡/ H
照片(8pass)10㎡/ H
照片(8pass)12㎡/ H
墨水Ink
種類Sort
水性墨水 / 弱溶劑墨水Water Based Ink / Eco Solvent Ink
水性墨水:水性染料、昇華染料Water Based Ink: dye ink 、Sublimation ink
容量Capacity
四色:440cc x 2/色 , 1000cc/色
耗材Media
大小Width
1620 mm
2500 mm
材料Sort
PP纸、灯片、胶片、高光相纸、涂层纸、硫酸纸等PP Sythentic Paper、Vinyl Sheet、Film、Coated Paper、Acid Proof Paper etc.
裁切 Media Cutting
裁切方向:Y方向Cutting in Y direction by cutter on the head
加熱裝置Media Heater
前、中、後三段式加熱Pre/Print/Post heater
收紙裝置Media Take-up Device
收紙裝置可選擇內收或外收Roll take-up device (Standard),inside/outside selectable
介面Interface
USB 2.0
网线插口Ethernet
電源需求Power
AC 100 V - 120 V ± 10 %、AC 220 V - 240 V ± 10 %、50 / 60 ± 1 Hz
操作環境Operation Environments
溫度 : 20°C ~ 35°C ,濕度 : 35%RH ~ 65%RH
外觀尺寸 Dimensions ( W x D x H )
2,538 x 739 x 1,424 mm
3,650x1,302x1,424mm
重量 Weight
120 kg
210kg
