【供应REXROTH品牌全系列直线运动产品，杜绝假货，欢迎订购。】价格_厂家

供应REXROTH品牌全系列直线运动产品，杜绝假货，欢迎订购。

1台起批

￥390.00

上海市闸北区共和新路2103弄4号

产品属性

图文详情

品牌推荐

品牌/型号

Rexroth/力士乐/R1622 212 20

滑轨宽度

型号

R1622 212 20

滑行轨迹

直线导轨

滑块个数

品牌

Rexroth/力士乐

种类

滑动导轨

材质

BOSCH REXROTH STAR滚珠导套,STAR直线轴承,STAR轴承,STAR线性轴承,STAR轴心,STAR钢轴.STAR滚珠导套,STAR可调式滚珠导套,STAR可调式直线轴承. STAR直线轴承、STAR导套,力士乐直线轴承、力士乐导套.大量现货库存供应STAR（REXROTH）德星滚珠导套，导套，STAR轴心, STAR直线轴承、STAR导套,力士乐直线轴承、力士乐导套。

电话：13761222920。QQ：1003960621。

Bosch Rexroth - Guide Rails - Type 2047

Ball Rail® Systems

Guide Rail Made of Corrosion-resistant Steel

for mounting from below

Specifications:

Size	Accuracy class	Guide Rail With Rail Seal Part number, Rail length	Hole spacing T(mm)
15*	P	2047-102-31,...	60
	H	2047-103-31,...
	N	2047-104-31,...
20*	P	2047-802-31,...	60
	H	2047-803-31,...
	N	2047-804-31,...
25	P	2047-209-31,...	60
	H	2047-203-31,...
	N	2047-204-31,...
30	P	2047-709-31,...	80
	H	2047-703-31,...
	N	2047-704-31,...
35	P	2047-309-31,...	80
	H	2047-303-31,...
	N	2047-304-31,...

Bosch Rexroth - Runner Blocks - Type 1621

Ball Rail Systems (Generation 2)
Runner Block, Steel Version
with Ball Chain as an Option

Slimline, high
Versions:
- Runner block without ball chain:
for part numbers, see table
- Runner block with ball chain:
part numbers 1621-...-22

Dynamic characteristics
Speed Vmax=5 m/s
Acceleration amax=500 m/s2

Specifications:

Size	Accuracy class	Part numbers for runner blocks
Size	Accuracy class	up to approx. 10 um clearance	Preload 0.02 C	Preload 0.08 C	Preload 0.13 C
15	P	-	1621-112-20	1621-122-20	1621-132-20
	H	1621-193-20	1621-113-20	1621-123-20	-
	N	1621-194-20	1621-114-20	1621-124-20	-
25	P	-	1621-212-20	1621-222-20	1621-232-20
	H	1621-293-20	1621-213-20	1621-223-20	-
	N	1621-294-20	1621-214-20	1621-224-20	-
30	P	-	1621-712-20	1621-722-20	1621-732-20
	H	1621-793-20	1621-713-20	1621-723-20	-
	N	1621-794-20	1621-714-20	1621-724-20	-
35	P	-	1621-312-20	1621-322-20	1621-332-20
	H	1621-393-20	1621-313-20	1621-323-20	-
	N	1621-394-20	1621-314-20	1621-324-20	-
45 *	P	-	1621-412-20	1621-422-20	1621-432-20
	H	1621-493-20	1621-413-20	1621-423-20	-
	N	1621-494-20	1621-414-20	1621-424-20	-
45 **	P	-	1621-412-10	1621-422-10	1621-432-10
	H	1621-493-10	1621-413-10	1621-423-10	-
	N	1621-494-10	1621-414-10	1621-424-10	-
55	P	-	1621-512-10	1621-522-10	1621-532-10
	H	1621-593-10	1621-513-10	1621-523-10	-
	N	1621-594-10	1621-514-10	1621-524-10

Bosch Rexroth - Runner Blocks - Type 1622

Ball Rail Systems (Generation 2)
Runner Block, Steel Version
with Ball Chain as an Option

Slimline
Versions:
- Runner block without ball chain:
for part numbers, see table
- Runner block with ball chain:
part numbers 1622-...-22

Dynamic characteristics
Speed Vmax=5 m/s
Acceleration amax=500 m/s2

Specifications:

Size	Accuracy class	Part numbers for runner blocks
Size	Accuracy class	up to approx. 10 um clearance	Preload 0.02 C	Preload 0.08 C	Preload 0.13 C
15	N	R1622 194 20	R1622 114 20	R1622 124 20	-
	H	R1622 193 20	R1622 113 20	R1622 123 20	-
	P	-	R1622 112 20	R1622 122 20	-
	XP	-	R1622 118 20	R1622 128 20	R1622 138 20
20	N	R1622 894 20	R1622 814 20	R1622 824 20	-
	H	R1622 893 20	R1622 813 20	R1622 823 20	-
	P	-	R1622 812 20	R1622 822 20	-
	XP	-	R1622 818 20	R1622 828 20	R1622 838 20
25	N	R1622 294 20	R1622 214 20	R1622 224 20	-
	H	R1622 293 20	R1622 213 20	R1622 223 20	-
	P	-	R1622 212 20	R1622 222 20	-
	XP	-	R1622 218 20	R1622 228 20	R1622 238 20
30	N	R1622 794 20	R1622 714 20	R1622 724 20	-
	H	R1622 793 20	R1622 713 20	R1622 723 20	-
	P	-	R1622 712 20	R1622 722 20	-
	XP	-	R1622 718 20	R1622 728 20	R1622 738 20
35	N	R1622 394 20	R1622 314 20	R1622 324 20	-
	H	R1622 393 20	R1622 313 20	R1622 323 20	-
	P	-	R1622 312 20	R1622 322 20	-
	XP	-	R1622 318 20	R1622 328 20	R1622 338 20
45	N	R1622 494 20	R1622 414 20	R1622 424 20	-
	H	R1622 493 20	R1622 413 20	R1622 423 20	-
	P	-	R1622 412 20	R1622 422 20	-
	XP	-	R1622 418 20	R1622 428 20	R1622 438 20
55	N	R1622 594 10	R1622 514 10	R1622 524 10	-
	H	R1622 593 10	R1622 513 10	R1622 523 10	-
	P	-	R1622 512 10	R1622 522 10	R1622 532 10
65	N	R1622 694 10	R1622 614 10	R1622 624 10	-
	H	R1622 693 10	R1622 613 10	R1622 623 10	-
	P	-	R1622 612 10	R1622 622 10	R1622 632 10

Bosch Rexroth - Runner Blocks - Type 1623

Ball Rail Systems (Generation 2)
Runner Block, Steel Version
with Ball Chain as an Option
Runner block 1623-

Slimline, long
Versions:
- Runner block without ball chain:
for part numbers, see table
- Runner block with ball chain:
part numbers 1623-...-22

Dynamic characteristics
Speed Vmax=5 m/s
Acceleration amax=500 m/s2

Specifications:

Size	Accuracy class	Part numbers for runner blocks
Size	Accuracy class	up to approx. 10 um clearance	Preload 0.02 C	Preload 0.08 C	Preload 0.13 C
15	N	1623-194-20	1623-114-20	-	-
20	P	-	1623-812-20	1623-822-20	1623-832-20
	H	1623-893-20	1623-813-20	1623-823-20	-
	N	1623-894-20	1623-814-20	1623-824-20	-
25	P	-	1623-212-20	1623-222-20	1623-232-20
	H	1623-293-20	1623-213-20	1623-223-20	-
	N	1623-294-20	1623-214-20	1623-224-20	-
30	P	-	1623-712-20	1623-722-20	1623-732-20
	H	1623-793-20	1623-713-20	1623-723-20	-
	N	1623-794-20	1623-714-20	1623-724-20	-
35	P	-	1623-312-20	1623-322-20	1623-332-20
	H	1623-393-20	1623-313-20	1623-323-20	-
	N	1623-394-20	1623-314-20	1623-324-20	-
45 *	P	-	1623-412-20	1623-422-20	1623-432-20
	H	1623-493-20	1623-413-20	1623-423-20	-
	N	1623-494-20	1623-414-20	1623-424-20	-
45 **	P	-	1623-412-10	1623-422-10	1623-432-10
	H	1623-493-10	1623-413-10	1623-423-10	-
	N	1623-494-10	1623-414-10	1623-424-10	-
55	P	-	1623-512-10	1623-522-10	1623-532-10
	H	1623-593-10	1623-513-10	1623-523-10	-
	N	1623-594-10	1623-514-10	1623-524-10	-
65	P	-	1623-612-10	1623-622-10	1623-632-10
	H	1623-693-10	1623-613-10	1623-623-10	-
	N	1623-694-10	1623-614-10	1623-624-10

Bosch Rexroth - Runner Blocks - Type 1624

Ball Rail Systems (Generation 2)
Runner Block, Steel Version
with Ball Chain as an Option

Slimline, high, long
Versions:
- Runner block without ball chain:
for part numbers, see table
- Runner block with ball chain:
part numbers 1624-...-22

Dynamic characteristics
Speed Vmax=5 m/s
Acceleration amax=500 m/s2

Specifications:

Size	Accuracy class	Part numbers for runner blocks
Size	Accuracy class	up to approx. 10 um clearance	Preload 0.02 C	Preload 0.08 C	Preload 0.13 C
25	P	-	1624-212-20	1624-222-20	1624-232-20
	H	1624-293-20	1624-213-20	1624-223-20	-
	N	1624-294-20	1624-214-20	1624-224-20	-
30	P	-	1624-712-20	1624-722-20	1624-732-20
	H	1624-793-20	1624-713-20	1624-723-20	-
	N	1624-794-20	1624-714-20	1624-724-20	-
35	P	-	1624-312-20	1624-322-20	1624-332-20
	H	1624-393-20	1624-313-20	1624-323-20	-
	N	1624-394-20	1624-314-20	1624-324-20	-
45 *	P	-	1624-412-20	1624-422-20	1624-432-20
	H	1624-493-20	1624-413-20	1624-423-20	-
	N	1624-494-20	1624-414-20	1624-424-20	-
45 **	P	-	1624-412-10	1624-422-10	1624-432-10
	H	1624-493-10	1624-413-10	1624-423-10	-
	N	1624-494-10	1624-414-10	1624-424-10	-
55	P	-	1624-512-10	1624-522-10	1624-532-10
	H	1624-593-10	1624-513-10	1624-523-10	-
	N	1624-594-10	1624-514-10	1624-524-10

Bosch Rexroth - Runner Blocks - Type 1651

Ball Rail Systems (Generation 2)
Runner Block, Steel Version
with Ball Chain as an Option

Standard width
Versions:
- Runner block without ball chain:
for part numbers, see table
- Runner block with ball chain:
part numbers 1651-...-22

Dynamic characteristics
Speed Vmax=5 m/s
Acceleration amax=500 m/s2

Specifications:

Size	Accuracy class	Part numbers for runner blocks
Size	Accuracy class	up to approx. 10 um clearance	Preload 0.02 C	Preload 0.08 C	Preload 0.13 C
15	N	R1651 194 20	R1651 114 20	R1651 124 20	-
	H	R1651 193 20	R1651 113 20	R1651 123 20	-
	P	-	R1651 112 20	R1651 122 20	-
	XP	-	R1651 118 20	R1651 128 20	R1651 138 20
	SP	-	R1651 111 20	R1651 121 20	R1651 131 20
	UP	-	R1651 119 20	R1651 129 20	R1651 139 20
20	N	R1651 894 20	R1651 814 20	R1651 824 20	-
	H	R1651 893 20	R1651 813 20	R1651 823 20	-
	P	-	R1651 812 20	R1651 822 20	-
	XP	-	R1651 818 20	R1651 828 20	R1651 838 20
	SP	-	R1651 811 20	R1651 821 20	R1651 831 20
	UP	-	R1651 819 20	R1651 829 20	R1651 839 20
25	N	R1651 294 20	R1651 214 20	R1651 224 20	-
	H	R1651 293 20	R1651 213 20	R1651 223 20	-
	P	-	1651-212-20	1651-222-20	-
	XP	-	R1651 218 20	R1651 228 20	R1651 238 20
	SP	-	R1651 211 20	R1651 221 20	R1651 231 20
	UP	-	R1651 219 20	R1651 229 20	R1651 239 20
30	N	R1651 794 20	R1651 714 20	R1651 724 20	-
	H	R1651 793 20	R1651 713 20	R1651 723 20	-
	P	-	R1651 712 20	R1651 722 20	-
	XP	-	R1651 718 20	R1651 728 20	R1651 738 20
	SP	-	R1651 711 20	R1651 721 20	R1651 731 20
	UP	-	R1651 719 20	R1651 729 20	R1651 739 20
35	N	R1651 394 20	R1651 314 20	R1651 324 20	-
	H	R1651 393 20	R1651 313 20	R1651 323 20	-
	P	-	R1651 312 20	R1651 322 20	-
	XP	-	R1651 318 20	R1651 328 20	R1651 338 20
	SP	-	R1651 311 20	R1651 321 20	R1651 331 20
	UP	-	R1651 319 20	R1651 329 20	R1651 339 20
45	N	R1651 494 20	R1651 414 20	R1651 424 20	-
	H	R1651 493 20	R1651 413 20	R1651 423 20	-
	P	-	R1651 412 20	R1651 422 20	-
	XP	-	R1651 418 20	R1651 428 20	R1651 438 20
	SP	-	R1651 411 20	R1651 421 20	R1651 431 20
	UP	-	R1651 419 20	R1651 429 20	R1651 439 20
55	N	R1651 594 10	R1651 514 10	R1651 524 10	-
	H	R1651 593 10	R1651 513 10	R1651 523 10	-
	P	-	R1651 512 10	R1651 522 10	R1651 532 10
	SP	-	R1651 511 10	R1651 521 10	R1651 531 10
	UP	-	R1651 519 10	R1651 529 10	R1651 539 10
65	N	R1651 694 10	R1651 614 10	R1651 624 10	-
	H	R1651 693 10	R1651 613 10	R1651 623 10	-
	P	-	R1651 612 10	R1651 622 10	R1651 632 10
	SP	-	R1651 611 10	R1651 621 10	R1651 631 10
	UP	-	R1651 619 10	R1651 629 10	R1651 639 10

Bosch Rexroth - Runner Blocks - Type 1653

Ball Rail Systems
Runner Block, Steel Version
with Ball Chain as an Option

Standard width, long
Versions:
- Runner block without ball chain:
for part numbers, see table
- Runner block with ball chain:
part numbers 1653-...-22

Dynamic characteristics
Speed Vmax=5 m/s
Acceleration amax=500 m/s2

Specifications:

Size	Accuracy class	Part numbers for runner blocks
Size	Accuracy class	up to approx. 10 um clearance	Preload 0.02 C	Preload 0.08 C	Preload 0.13 C
15	N	R1653 194 20	R1653 114 20	R1653 124 20	-
	H	R1653 193 20	R1653 113 20	R1653 123 20	-
	P	-	R1653 112 20	R1653 122 20	-
	XP	-	R1653 118 20	R1653 128 20	R1653 138 20
	SP	-	R1653 111 20	R1653 121 20	R1653 131 20
	UP	-	R1653 119 20	R1653 129 20	R1653 139 20
20	N	R1653 894 20	R1653 814 20	R1653 824 20	-
	H	R1653 893 20	R1653 813 20	R1653 823 20	-
	P	-	R1653 812 20	R1653 822 20	-
	XP	-	R1653 818 20	R1653 828 20	R1653 838 20
	SP	-	R1653 811 20	R1653 821 20	R1653 831 20
	UP	-	R1653 819 20	R1653 829 20	R1653 839 20
25	N	R1653 294 20	R1653 214 20	R1653 224 20	-
	H	R1653 293 20	R1653 213 20	R1653 223 20	-
	P	-	R1653 212 20	R1653 222 20	-
	XP	-	R1653 218 20	R1653 228 20	R1653 238 20
	SP	-	R1653 211 20	R1653 221 20	R1653 231 20
	UP	-	R1653 219 20	R1653 229 20	R1653 239 20
30	N	R1653 794 20	R1653 714 20	R1653 724 20	-
	H	R1653 793 20	R1653 713 20	R1653 723 20	-
	P	-	R1653 712 20	R1653 722 20	-
	XP	-	R1653 718 20	R1653 728 20	R1653 738 20
	SP	-	R1653 711 20	R1653 721 20	R1653 731 20
	UP	-	R1653 719 20	R1653 729 20	R1653 739 20
35	N	R1653 394 20	R1653 314 20	R1653 324 20	-
	H	R1653 393 20	R1653 313 20	R1653 323 20	-
	P	-	R1653 312 20	R1653 322 20	-
	XP	-	R1653 318 20	R1653 328 20	R1653 338 20
	SP	-	R1653 311 20	R1653 321 20	R1653 331 20
	UP	-	R1653 319 20	R1653 329 20	R1653 339 20
45	N	R1653 494 20	R1653 414 20	R1653 424 20	-
	H	R1653 493 20	R1653 413 20	R1653 423 20	-
	P	-	R1653 412 20	R1653 422 20	-
	XP	-	R1653 418 20	R1653 428 20	R1653 438 20
	SP	-	R1653 411 20	R1653 421 20	R1653 431 20
	UP	-	R1653 419 20	R1653 429 20	R1653 439 20
55	N	R1653 594 10	R1653 514 10	R1653 524 10	-
	H	R1653 593 10	R1653 513 10	R1653 523 10	-
	P	-	R1653 512 10	R1653 522 10	R1653 532 10
	SP	-	R1653 511 10	R1653 521 10	R1653 531 10
	UP	-	R1653 519 10	R1653 529 10	R1653 539 10
65	N	R1653 694 10	R1653 614 10	R1653 624 10	-
	H	R1653 693 10	R1653 613 10	R1653 623 10	-
	P	-	R1653 612 10	R1653 622 10	R1653 632 10
	SP	-	R1653 611 10	R1653 621 10	R1653 631 10
	UP	-	R1653 619 10	R1653 629 10	R1653 639 10

上海亿肯传动机械有限公司
联系人;郭永生

手机：13761222920，

QQ：329473055

电话;021-56511160

传真;021-56511160

E-Mail:xdbearing0309@hotmail.com

地址;上海市闸北区共和新路2103弄4号202室
