替代 SICK 感应式接近传感器销售IM12-02BCP-ZC1
乐清市智灵电气有限公司
柳市镇东仁宕工业区
产品属性
图文详情
品牌推荐
品牌/型号
CILI/IM12-02BCP-ZC1
检测距离
1-4（mm）
额定电压
10-30DC/90-250AC（V）V
加工定制
是
额定电流
1-10（A）A
型号
IM12-02BCP-ZC1
类型
电容式接近开关
品牌
CILI
货期
5工作日
产品认证
CE
反应频率
NPN/PNP
产品简介
"Indispensable in all machines"
Inductive proximity switch for the contactless detection of metal objectsMy companya development pioneer and one of the leading manufacturers of inductive sensors – the heart and soul of all machines. As inpidual items or in large quantities - we deliver standard products in various housing sizes with different sensing distances. But always with the same high quality.
| ||||||||||||||||||||||||||||||
| Features | |||
 | Design: | Cylindrical | |
| Thread size: | M12 x 1 | |
| Sensing range Sn: | 2 mm | |
| Assured sensing range Sa: | 1.62 mm | |
| Installation type: | Flush | |
| Switching frequency: | 1,000 Hz | |
| Output type: | PNP or NPN | |
| Output function: | NC or NO | |
| Electrical wiring: | DC 4-wire | |
| Enclosure rating: | IP 67 1) | |
| Connection type: | Connector M12, 4-pin | |
| Housing: | Standard | |
| Output characteristic: | Wire configurable | |
| 1) According to EN 60529 | |
| Mechanics/electronics | |||
| Supply voltage: | 10 V DC ... 30 V DC | |
| Residual ripple: | ≤ 10 % 1) | |
| Voltage drop: | ≤ 1.2 V 2) | |
| Power consumption: | ≤ 30 mA 3) | |
| Time delay before availability: | ≤ 250 ms | |
| Hysteresis: | 2 % ... 10 % | |
| Repeatability: | ≤ 5 % 4) 5) | |
| Temperature drift (% of Sr): | ± 10 % | |
| EMC: | According to EN 60947-5-2 | |
| Output current Ia: | ≤ 100 mA | |
| Wire-break protection: | 0 | |
| Short-circuit protection: |  | |
| Reverse polarity protection: | | |
| Power-up pulse protection: | | |
| Shock/vibration: | 30 g, 11 ms / 10 ... 55 Hz, 1 mm | |
| Ambient operating temperature: | -25 °C ... 70 °C | |
| Housing material: | Metal, Nickel-plated brass | |
| Housing cap material: | Plastic | |
| Housing length: | 75 mm | |
| Thread length: | 53 mm | |
| Tightening torque, max.: | ≤ 10 Nm | |
| 1) Of VS 2) At Ia max 3) Without load 4) Ub and Ta constant 5) Of Sr | |
| Reduction factors | |||
| Note: | The values are reference values which may vary | |
| Stainless steel (V2A, 304): | Ca. 0.8 | |
| Copper (Cu): | Ca. 0.4 | |
| Aluminum (Al): | Ca. 0.45 | |
| Installation note | |||
| A: | 6 mm | |
| B: | 12 mm | |
| C: | 12 mm | |
| D: | 6 mm | |
| F: | 16 mm | |
| Remark: | Associated graphic see "Installation" | |
产品图片
公司介绍
1、本公司生产销售：超声波传感器、接近开关、光电开关、也能够根据客户要求，根据国外的进口传感器参数生产性能外形能代替国外进口传感器的产品。
2、本公司同时也代理销售各类进口传感器：堡盟Baumer、倍加福P+F、巴鲁夫BALLUFF、图尔克Turck、科瑞Contrinex、欧姆龙omron、易福门IFM、等等~
3、本公司还专业为客户提供给类跑偏开关、拉绳开关、安全光幕、安全光栅。
4、本公司今年重点开发超声波传感器国产化技术，扮演传感器行业领头雁的角色，把国外的超声波技术百纳入微，生产销售性能参数和国外超声波一样水准，价格优惠的超声波传感器。
欢迎询价、下单！
