尼龙网过滤器
Nylon Mesh Filter
产品特性:
用途:广泛用于家用、商业、工业中央空调系统新风口空气的保护性预过滤;
特性:风量大、阻力小,可重复清洗使用,使用周期长,性价比高;
滤料:PP纤维纺织黑色尼龙网
Speciality:
Common Applications: It is widely used as the protective pre-filtration in central air conditioning system of household, commerce and industry.
Features: high airflow, low resistance, long working life, economical and it can be used repeatedly.
Filter Media: PP fiber textile black nylon net
技术参数(Specification):
型号 Type | 尺寸Dimensions W*H*D (mm) | 额定风量 Rated Airflow (m3/h) | 初阻力 Initial Resistance (Pa) | 外框 Frame |
SHW-NL | 595*595*10 | 3400 | 5 | 铝合金 Aluminum alloy 镀锌板 Galvanized sheet |
595*495*10 | 3200 |
495*495*10 | 2800 |
595*595*20 | 3400 | 10 |
595*495*20 | 3200 |
495*495*20 | 2800 |
注:可按客户要求订做
Note:Other specifications are available on request
