The Gotop GT-1010-MTBD is a compl
ete GPS/BeiDou engine module that featu
res super sensitivity, ultra low power and
small form factor. The GPS/BeiDou signal
is applied to the antenna input of modul
e, and a complete serial data message w
ith position, velocity and time information i
s presented at the serial interface with N
MEA protocol or custom protocol.
Its –165dBm tracking sensitivity exten
ds positioning coverage into place like ur
ban canyons and dense foliage environm
ent where the GPS/BeiDou was not possi
ble before. The small form factor and low
power consumption make the module ea
sy to integrate into portable device like P
NDs, mobile phones, cameras and vehicle
navigation systems.
Applications
? LBS (Location Based Service)
? PND (Portable Navigation Device)
? Vehicle navigation system
? Mobile phone
Figure 1: GT-1010-MTBD Top View
Features
? Build on high performance, low-power
MT3333chipset
? Ultra high sensitivity: -165dBm
? Extremely fastTTFFat low signal level
? Built in high gain LNA
? Low power consumption:Max18mA@3.
3V
? NMEA-0183 compliant protocol or cust
om protocol
? Operating voltage: 2.8V to 4.3V
? Operating temperature range:-40to85℃
? SMD type with stamp holes
? Small form factor:9.6x9.6x2.0mm
? RoHS compliant (Lead-free)
