作为一种自动化的摆动机针缝合机，专门设计用作密封系统（例如，纽朗KS密封机）的一部分。它具备如下特点：连续上料：当袋子通过缝合头时，调准的机针将以圆周旋转形式移动，从而可消除较长的针孔，避免机针和缝线断裂，并实现无泄漏缝合。电动进料辊可确保袋子上料的正确性，同时避免对袋子造成损害（有时由进料板引起）。DS-7A型配有机动缝线切刀。DS-7C型配有气动铡刀型皱纹胶带切刀。
Standard Specification | Specs | Sealing speed | Heater (W) | Drive (kW) | Power (kW) | Range | Capacity | Sealer | Sewer | KS-12 | 6 ~ 10m/min | 500 x 4 | 0.4 | 0.4 | 3 | KS-12C | KS-13 | 500 x 6 | 0.4 | 4 | KS-13C | KS-13D | KS-13DC | KS-14 | 500 x 8 | 0.4 | 5 | KS-14C | KS-14D | KS-14DC | KS-16 | 500 x 12 | 0.75 | 7.5 | KS-16C | KS-16D | KS-16DC |
|
Standard Specification | Specs | Dimensions (mm) | Weight
(kg) | Options | Applications | Length | Width | Dust cleaner | Crepe tape | KS-12 | 2,100 | 1,020 | ca.350 | - | - | Over-tape
Innermost ply
PE film seal. | KS-12C | 2,450 | 1,100 | ca.400 | - | ○ | KS-13 | 2,200 | 1,020 | ca.380 | - | - | For flat 3
paper plies.
Over-tape
inner ply seal | KS-13C | 2,650 | 1,100 | ca.450 | - | ○ | KS-13D | 2,590 | 1,250 | ca.420 | ○ | - | KS-13DC | 3,070 | 1,250 | ca.500 | ○ | ○ | KS-14 | 2,500 | 1,020 | ca.420 | - | - | For flat 4
paper plies.
Over-tape
inner ply seal | KS-14C | 2,900 | 1,100 | ca.500 | - | ○ | KS-14D | 2,850 | 1,250 | ca.460 | ○ | - | KS-14DC | 3,350 | 1,250 | ca.550 | ○ | ○ | KS-16 | 3,000 | 1,020 | ca.500 | - | - | For flat 6
paper plies &
gusseted 3
paper plies.
Over-tape
inner ply seal | KS-16C | 3,300 | 1,100 | ca.600 | - | ○ | KS-16D | 3,260 | 1,250 | ca.550 | ○ | - | KS-16DC | 3,720 | 1,250 | ca.650 | ○ | ○ |
|
- Temp. adjust range 0 to 400℃
- Air req. 200NL/min(at 0.5MPa) Pressure 0.5Mpa(5kg/c㎡) (varies with speed)
- Sealer height adjust range 800～1400mm
- Add 0.55KW(50Hz) or 0.72KW(60Hz) power when optional dust cleaner is installed.
- Above speeds are not guaranteed ones. They are given for reference only.
- Length of the machine (L) varies slightly between manual insertion type and packaging machine coupling type.
- ＫＳ ー 1□ Ｄ
- Kraft sealer ― 1：Rear sewer □：Heater pairs Ｄ：Dust cleaner Ｓ：Crepe tap
|
