数控刀柄BT30钻孔刀头BT40立铣刀把ER夹头机械五金柄钻头刀柄
深圳市鲁海阳精密机械配件有限公司
中国 深圳
产品属性
图文详情
品牌推荐
品牌
其他
型号
BT40-ER40
类型
BT40-ER40
进口
国产
加工定制
加工定制
材质
高速钢
适用范围
CNC电脑锣加工中心精雕机广泛
重量
1.950kg
| 型号 Model No. | 规格 | 尺寸 Size | 重量 KGS | ||||||
| L | L1 | D | d1 | d2 | d3 | T | |||
| BT30 | BT30-ER11-60 | 108.4 | 60 | 46 | 19 | 11 | 19 | M6×1P | 0.45 |
| BT30-ER11-70 | 118.4 | 70 | 0.5 | ||||||
| BT30-ER11-100 | 148.4 | 100 | 0.6 | ||||||
| BT30-ER16-60 | 118.4 | 60 | 28 | 16 | 28 | M11×1P | 0.5 | ||
| BT30-ER16-70 | 118.4 | 70 | 0.55 | ||||||
| BT30-ER16-100 | 148.4 | 100 | 0.8 | ||||||
| BT30-ER16-120 | 168.4 | 120 | 0.95 | ||||||
| BT30-ER20-60 | 108.4 | 60 | 34 | 20 | 34 | M14×1P | 0.7 | ||
| BT30-ER20-70 | 118.4 | 70 | 0.75 | ||||||
| BT30-ER20-100 | 148.4 | 100 | 0.9 | ||||||
| BT30-ER25-60 | 108.4 | 60 | 42 | 25 | 42 | M18×1P | 0.65 | ||
| BT30-ER25-70 | 118.4 | 70 | 0.7 | ||||||
| BT30-ER25-100 | 148.4 | 100 | 1.45 | ||||||
| BT30-ER32-60 | 108.4 | 60 | 50 | 32 | 45 | M22×1.5P | 0.8 | ||
| BT30-ER32-70 | 118.4 | 70 | 0.85 | ||||||
| BT30-ER32-100 | 148.4 | 100 | 1 | ||||||
| BT30-ER40-80 | 128.4 | 80 | 63 | 40 | 63 | M28×1.5P | 1.1 | ||
| BT30-ER40-100 | 148.4 | 100 | 1.3 | ||||||
| BT40 | BT40-ER11-60 | 125.4 | 60 | 63 | 19 | 11 | 19 | M6×1P | 1.2 |
| BT40-ER11-70 | 118.4 | 70 | 1.25 | ||||||
| BT40-ER11-100 | 165.4 | 100 | 1.3 | ||||||
| BT40-ER16-70 | 135.4 | 70 | 28 | 16 | 28 | M11×1P | 1.36 | ||
| BT40-ER16-100 | 165.4 | 100 | 1.54 | ||||||
| BT40-ER16-125 | 190.4 | 125 | 1.6 | ||||||
| BT40-ER16-150 | 215.4 | 150 | 1.86 | ||||||
| BT40-ER20-70 | 135.4 | 70 | 34 | 20 | 34 | M14×1P | 1.7 | ||
| BT40-ER20-100 | 165.4 | 100 | 1.8 | ||||||
| BT40-ER20-150 | 215.4 | 150 | 2.1 | ||||||
| BT40-ER25-70 | 135.4 | 70 | 42 | 25 | 42 | M18×1P | 1.9 | ||
| BT40-ER25-100 | 165.4 | 100 | 2.25 | ||||||
| BT40-ER25-150 | 215.4 | 150 | 2.75 | ||||||
| BT40-ER32-70 | 135.4 | 70 | 50 | 32 | 50 | M22×1.5P | 2.5 | ||
| BT40-ER32-100 | 165.4 | 100 | 2.8 | ||||||
| BT40-ER32-125 | 190.4 | 125 | 3.0 | ||||||
| BT40-ER32-150 | 215.4 | 150 | 3.05 | ||||||
| BT40-ER40-70 | 135.4 | 70 | 63 | 40 | 63 | M28×1.5P | 2.3 | ||
| BT40-ER40-80 | 145.4 | 80 | 2.5 | ||||||
| BT40-ER40-100 | 165.4 | 100 | 3.1 | ||||||
| BT40-ER40-120 | 185.4 | 120 | 3.7 | ||||||
| BT40-ER40-150 | 215.4 | 150 | 4.1 | ||||||
| BT40-ER50-85 | 150.4 | 85 | 78 | 50 | 59 | M28×1.5P | 3.1 | ||
| BT40-ER50-100 | 165.4 | 100 | 3.2 | ||||||
| BT50 | BT50-ER16-70 | 171.8 | 70 | 100 | 28 | 16 | 28 | M11×1P | 4.05 |
| BT50-ER16-100 | 208.8 | 100 | 4.2 | ||||||
| BT50-ER16-135 | 236.8 | 135 | 4.4 | ||||||
| BT50-ER16-150 | 251.8 | 150 | 4.45 | ||||||
| BT50-ER16-165 | 266.8 | 165 | 4.5 | ||||||
| BT50-ER16-200 | 301.8 | 200 | 4.8 | ||||||
| BT50-ER20-70 | 171.8 | 70 | 34 | 20 | 34 | M14×1P | 4.2 | ||
| BT50-ER20-100 | 191.8 | 100 | 4.25 | ||||||
| BT50-ER20-135 | 236.8 | 135 | 4.55 | ||||||
| BT50-ER20-150 | 251.8 | 150 | 4.7 | ||||||
| BT50-ER20-165 | 266.8 | 165 | 4.8 | ||||||
| BT50-ER20-200 | 301.8 | 200 | 4.9 | ||||||
| BT50-ER20-250 | 351.8 | 250 | 5.2 | ||||||
| BT50-ER25-70 | 171.8 | 70 | 42 | 25 | 42 | M18×1P | 4.2 | ||
| BT50-ER25-100 | 206.8 | 100 | 4.4 | ||||||
| BT50-ER25-135 | 236.8 | 135 | 4.7 | ||||||
| BT50-ER25-150 | 251.8 | 150 | 4.8 | ||||||
| BT50-ER25-165 | 266.8 | 165 | 5 | ||||||
| BT50-ER25-200 | 301.8 | 200 | 5.2 | ||||||
| BT50-ER25-250 | 351.8 | 250 | 5.5 | ||||||
| BT50-ER32-70 | 171.8 | 70 | 50 | 32 | 50 | M22×1.5P | 4.6 | ||
| BT50-ER32-100 | 201.8 | 100 | 4.8 | ||||||
| BT50-ER32-135 | 236.8 | 135 | 5 | ||||||
| BT50-ER32-150 | 251.8 | 150 | 5.3 | ||||||
| BT50-ER32-165 | 266.8 | 165 | 5.4 | ||||||
| BT50-ER32-200 | 301.8 | 200 | 5.5 | ||||||
| BT50-ER32-250 | 351.8 | 250 | 5.8 | ||||||
| BT50-ER40-80 | 181.8 | 80 | 63 | 40 | 63 | M28×1.5P | 4.3 | ||
| BT50-ER40-100 | 201.8 | 100 | 4.4 | ||||||
| BT50-ER40-120 | 221.8 | 120 | 5.2 | ||||||
| BT50-ER40-135 | 236.8 | 135 | 5.5 | ||||||
| BT50-ER40-150 | 251.8 | 150 | 5.8 | ||||||
| BT50-ER40-200 | 301.8 | 200 | 6.7 | ||||||
| BT50-ER40-250 | 351.8 | 250 | 7.5 | ||||||
| BT50-ER40-300 | 401.8 | 300 | 8.4 | ||||||
| BT50-ER50-90 | 191.8 | 90 | 78 | 50 | 78 | M28×1.5P | 4.6 | ||
| BT50-ER50-120 | 221.8 | 120 | 5.5 | ||||||
| BT50-ER50-165 | 266.8 | 165 | |||||||
深圳SZLUSUN精密机械配件有限公司，专业生产数控机床附件产品的研究和开发，主要产品包括：数控刀柄（高速BT/ ER刀柄，ISO木工雕刻机刀柄，CAT高速刀柄，ISO刀柄，SK刀柄/ HSK/GSK高速度刀柄，无键槽NBT高速刀柄，莫氏锥度刀柄（MTA/ MTB），木工刀柄，一体式钻夹头），夹头（ER夹头，OZ夹头，SK夹头），直柄刀柄，超微粒合金钢立铣刀，车刀，端面铣削工具和刀盘，工具车/工具柜，钢线切割扳手。产品大量库存现货，可来样来图加工定做。欢迎来电来涵来样加工订做！
