S-4000系列是一款全自动拉伸包装系统，可以手动加载的叉车，也可以在网上与其他自动化设备。不稳定或过重的旋转的高柱堆叠负载的理想的包装。

S-4000配备了托盘-GRIP®，专利的解决方案，锁定的托盘，以减少你的负荷错峰，产品损坏和退货。

拉伸包装系统的工业设备新闻的读者评选为最佳品牌。
控制
处理器艾伦布拉德利的CompactLogixL32E

HIM /触摸屏艾伦布拉德利的PanelView600 +颜色

逻辑兰的Logix™采用RSLogix的5000



性能
峰值超过100个加载/小时的生产速度

最大负载对角线72“

最大负载高度75“电影高度

最大负载重量4000磅



负载处理
寻求负载™钳标准

总结防区80“

裹臂驱动HPAC变频

裹臂速度（可变）40RPM



电影传送系统
托盘-GRIP®标准

电影传送系统动力辊拉伸®PLUS

标准预拉伸250％

E-Z主题™辊小车标准

包装强制变量

电影容量10“轧辊直径

标准膜宽度20“



机械运输重量
运输重量约11450磅



服务
电气460V

气动3-5CFM @80 PSI

服务支持24小时 -7天/周



保3年无限次循环

````````````````····英文原介绍······································

The S-4000 Series is a fully
automatic stretch wrap system that can either be loaded manually by a forktruck
or can operate in-line with other automated equipment. Ideal wrapper for tall
column stacked loads that are unstable or too heavy to rotate.

The
S-4000 is equipped with Pallet-Grip®, the patented solution that locks your load
to the pallet to reduce load shifting, product damage, and returned goods.


Voted BEST BRAND in Stretch Wrapping Systems by readers of Industrial
Equipment News.

	Processor	Allen Bradley CompactLogix L32E
	HIM / Touchscreen	Allen Bradley PanelView 600+ Color
	Logic	Lan-Logix™ powered by RS Logix 5000

Performance

	Peak Production Speed	Over 100 loads/hr
	Maximum Load Diagonal	72"
	Maximum Load Height	75" Film Height
	Maximum Load Weight	4000 lbs

Load Handling

	Load-Seeking™ Clamp	Standard
	Wrap Arm Zone	80"
	Wrap Arm Drive	3 HP AC Inverter Duty
	Wrap Arm Speed (Variable)	40 RPM

Film Delivery System

	Pallet-Grip®	Standard
	Film Delivery System	Power Roller-Stretch® Plus
	Standard Pre-stretch	250%
	E-Z Thread™ Roll Carriage	Standard
	Wrapping Force	Variable
	Film Capacity	10" Roll Diameter
	Standard Film Width	20"

Machine Shipping Weight

	Approximate Shipping Weight	11,450 lbs

Service

	Electrical	460V
	Pneumatic	3-5 CFM @ 80 PSI
	Service Support	24 hrs - 7 days/wk

Warranty

3 years Unlimited cycles
