Item
项目 | Technical Norm
技术指标 |
Max. Output Wattage(最大输出功率) | 60W |
Input(输入特性) | Rated input voltage(额定输入电压范围) | 100-240VAC |
Range of input voltage (输入电压范围) | 90-264VAC |
Frequency(Hz) (输入频率范围) | 47-63Hz |
Power Factor (功率因素) | PF≥0.96@Full Load, 100-240VAC |
Input Current Max (最大输入电流) | 0.6AMax @Full Load,90VAC |
Start-up time (启动时间) | ＜2s@Full Load |
Unload Power Consumption(空载功耗) | ≤1W |
Inrush Current(涌入电流) | ＜20A Max.@Full Load,220VAC |
Output(输出特性) | Voltage(输出电压) | 30-40V |
Current(Convection)(输出电流)(A) | 1.5A |
Current Accuracy(电流精度) | ±3% |
Voltage Regulation(电压调整率) | # |
Load Regulation(负载调整率) | ≤1% |
Hold-up Time(输出保持时间) | 10ms max |
Out Current Ripple (输出电流纹波) | ＜150mAp-p@Full Load,220VAC |
Recommend maximum numbers of LED series(建议串联最大灯数量) | 12PCS(Vf≤3.3V) |
Efficiency(Typ.)(平均效率) | ≥87%@Full Load,220VAC |
Dimming(调光) | Dimmable
(调光) | 无 |
Dimming mode (调光模式) | 无 |
Dimming Current range (调光电流范围) | 无 |
Protection(保护特性) | Over load protection
(过载保护) | 115% |
Protection type: Auto Resume(保护类型:自动恢复) |
Over voltage protection
(过压保护) | 46V |
Protection type: Auto Resume(保护类型:自动恢复) |
Short circuit Protection(短路) | Protection type: Auto Resume(保护类型:自动恢复) |
Over Temperature Protection(过温保护) | Protection type: Auto Resume(保护类型:自动恢复) |
Hi-pot(耐压) | Input-Output(V.AC)(输入-输出) | 3000V/10mA/1min; 无飞狐，无击穿 |
Leakage Current(泄漏电流) | ＜3mA |
Isolation Resistance(绝缘阻抗) | Input-Output(V.AC)(输入-输出) | ≥10MΩ@500Vdc |
Environment(环境特性) | Operating Temperature(工作温度) | -20℃…+50℃ |
Storage Temperature(储存温度) | -20℃…+80℃ |
Humidity(湿度) | 10%-90%RH |
Life time | ＞30,000h@25℃ |
Others(其它) | Dimension(尺寸)(L×W×H) | 158*55*36 (L×W×H)mm |
Safety& EMC(安规与电磁兼容) | Approvel(认证) | CE/SAA |
Safety standards(安全标准) | EN 61347-1;
EN 61347-2-13 EN60598-1;
EN60598-2-6 |
EMI(电磁兼容发射) | EN55015;
EN61547 EN61000-3-2;
EN61000-3-3 |
EMS(电磁兼容抗扰度) | EN61547 Performance Criteria B EN 61000-4-5—1000V; Performance Criteria C |
Note(备注) | All parameters NOT specially mentioned are measured at rated input or max rated input, and
25℃ of ambient temperature(所有的参数无特别说明的都是在额定输入电压的上限值和25℃的环境温度下测得) |
