Part No.
型号 | Center
Frequency
(MHz)
中心频率(fo) | Band Width
(MHz) min.
带宽 | Insertion
Loss
(dB) max.
插入损耗 | Ripple in BW
(dB) max.
带内波动 | V.S.W.R
max
驻波比 | Attenuation
(dB) min.
(MHz)
衰减 | Dimension
W×H×L(max.)
(mm)
尺寸 | CAF35C2400C400A | 2400.0 | fo±200 | 2.0 | 1.0 | 1.6 | 40 at fo-540 | 23.0×4.0×11.0 | CAF355C980C40A | 980.0 | fo±20 | 2.5 | 0.6 | 1.5 | 70 at fo-230 | 20.0×5.8×12.0 | CAF356C1400C100A | 1400.0 | fo±50 | 2.5 | 1.0 | 1.5 | 20 at fo±70 | 23.0×5.8×13.0 | CAF357C2400C330A | 2400.0 | fo±165 | 4.5 | 1.0 | 1.8 | 35 at fo±300 | 26.0×5.8×11.5 | CAF358C2600C115A | 2600.0 | fo±57.5 | 3.5 | 0.6 | 1.8 | 50 at fo±160 | 29.0×5.8×11.0 | CAF37C1240C85A | 1240.0 | fo±42.5 | 2.5 | 0.8 | 1.5 | 35 at fo±100 | 26.0×4.0×14.0 | CAF38C1350C136A | 1350.0 | fo±68 | 3.0 | 0.5 | 1.5 | 45 at fo±140 | 29.0×4.0×13.0 | CAF42C2500C200A | 2500.0 | fo±100 | 2.0 | 1.0 | 1.5 | 10 at fo±300 | 9.0×4.8×9.0 | CAF43C915C26A | 915.0 | fo±13 | 2.8 | 1.0 | 1.5 | 12 at fo±32.5 | 9.5×4.8×10.0 | CAF52C1260C22A | 1260.0 | fo±11 | 1.3 | 0.5 | 1.5 | 15 at fo±150 | 15.0×5.8×10.5 | CAF54C1808C100A | 1808.0 | fo±50 | 1.5 | 0.5 | 1.5 | 50 at fo-200
35 at fo+200 | 25.0×5.8×11.5 | CAF55C1880C10A | 1880.0 | fo±5 | 1.5 | 0.5 | 1.5 | 45 at fo±140 | 30.0×5.8×11.0 | CAF56C720C08A | 720.0 | fo±4 | 3.0 | 0.5 | 1.5 | 50 at fo±50 | 35.0×5.8×16.0 | CAF57C1200C200A | 1200.0 | fo±100 | 3.0 | 1.0 | 1.5 | 40 at fo±200 | 40.0×5.8×15.0 | CAF58C1100C130A | 1100.0 | fo±65 | 2.0 | 1.0 | 1.5 | 25 at fo±100 | 45.0×5.8×12.5 | CAF63C4000C500A | 4000.0 | fo±250 | 2.5 | 1.0 | 2.0 | 5 at fo+395
15 at fo-395 | 23.0×6.8×10.5 | CAF64C1600C60A | 1600.0 | fo±30 | 1.2 | 0.5 | 1.6 | 15 at fo±100 | 29.0×6.8×12.5 | CAF66C1484C200A | 1484.0 | fo±100 | 1.0 | 0.4 | 2.0 | 35 at fo-200
20 at fo+200 | 41.0×6.8×15.5 | CAF67C1095C300A | 1095.0 | fo±150 | 2.0 | 1.0 | 2.0 | 20 at fo-200 | 47.0×6.8×12.5 | CAF68C1050C140A | 1050.0 | fo±70 | 3.5 | 1.0 | 1.8 | 55 at fo±150 | 52.0×6.8×12.0 | CAF74C410C03A | 410.0 | fo±1.5 | 3.5 | 0.5 | 1.5 | 40 at fo±20 | 27.0×7.5×25.0 | CAF75C285C24A | 285.0 | fo±12 | 3.0 | 0.5 | 1.5 | 40 at fo±40 | 39.0×8.3×32.0 | CAF76C500C80A | 500.0 | fo±40 | 3.0 | 1.0 | 1.8 | 15 at fo±80 | 45.5×8.3×22.0 | CAF77C720C100A | 720.0 | fo±50 | 3.0 | 1.0 | 2.0 | 55 at fo±130 | 52.0×8.3×16.0 | CAF78C390C30A | 390.0 | fo±15 | 3.0 | 1.0 | 1.5 | 40 at fo±35 | 59.0×8.3×29.0 | CAF85C1200C25A | 1200.0 | fo±12.5 | 5.0 | 1.0 | 2.0 | 35 at fo±27.5 | 39.0×8.3×12.5 | CAF86C1150C30A | 1150.0 | fo±15 | 3.0 | 0.5 | 1.5 | 45 at fo±50 | 51.0×8.3×10.0 |
|
Note:① Fo available on request. 频率可根据用户要求制造。
② Other parameters available on request. 其它参数指标可按照用户要求设计。 |
| 特点(FEATURES) |
.Various Size & Wide Frequency .多种尺寸、频率范围广
.Temperature Compensated .温度补偿
.Low Insertion Loss .低插损
.High frequency selectivity .高频率选择性 |
应用(APPLICATIONS)
|
.Base Station.Wireless LAN . 通信基站 .无线局域网
.Repeater .MMDS .通信转发器 .多重频道，多重定位系统
.Cellular phone .CDMAS .蜂窝式电话 .码分多路访问（通信）
.Cordless phone .IMT-2000S .无绳电话 .国际移动通讯
.Trunked Radio System(TRS) .GSM .中续无线系统 .全球数字移动电话系统
.PCS .DCS .个人移动通信系统 .无线局域网
.DECT .数字无绳电话
.Radar, Electronic counterwork .雷达、电子对抗
Aviation and Spaceflight, Navigation .军事、航空航天等领域 |
介質濾波器貼片式適用於無繩電話無線耳機無線麥克風等.頻率范圍可做到(470MHZ~5.8G)也可根據客戶要求設計制做.其特點是:尺寸小,阻帶衰減大.插入損耗低.穩定性好,選擇性好,可焊性好.
