产品型号:
产品名称:
产品类别:
产品规格:
本产品采用压力式温控器能在特低的电压下工作,不受电压的波动而影响电气性能。YXDF系列远红外电热食品烤炉是采用远红外辐射管为发热元件,以热辐射作用透入物体内部,加热速度快,被烤物品受热均匀,色味兼优,符合食品卫生标准。该烤炉,并采用分层各自独立控制结构,每一层的底火及面火均可以控制。
主要参数:
型号
规格
电 压
功率
外形尺寸
净重
YXD9D-1
一层一盘
220V
4.8kw/h
740×740×340mm
36kg
YXD8D-2
2.6kw/h
570×550×320mm
21kg
YXD-F18
二层二盘
7.2kw/h
740×740×650mm
69kg
YXD-F30
一层二盘
5.4kw/h
1240×850×520mm
90kg
YXD-F60
二层四盘
~3N380V
10.8kw/h
1240×850×1210mm
155kg
YXD-F90
三层六盘
16.2kw/h
1240×850×1610mm
220kg
Model:
Name:
Class:
detail:
This product is suitable for baking cakes and bread.
Adopted far infrared metal heating tube,fast heating and energy saving.
The temperature of the bake box could be adjusted from50-300℃.The temperature is too high.It is reliable and secure.
Double structures-bracket and the bottom of board expand the using scope.
Main Specification:
Model
Specification
Voltage
Power
Overall Dimensions
N.W
One Layer And One Pan
570×550×3200mm
Two Layers And Two Pans
One Layer And Two Pans
Two Layers And Four Pans
Three Layers And Six Pans
相关图片如下所示:
