技术参数
电 压: AC100V~240V/50~60Hz
镇 流 器: 电子镇流器
灯 泡: OSRAM SIRIUS系列 HRI 330W
色 温: 8500K
灯泡寿命: 1500小时
颜 色: 14种颜色+白光
图 案: 8个旋转图案 + 4个光圈
棱 镜: 两个可以双向旋转的棱镜盘，光束角度可以自由缩放
镜 头: 高精密多组胶合光学镜头
柔光效果: 可调节柔光角度
光 束: 多级光束角度变化效果
调 焦: 线性调焦
调 光: 0-100%线性调节
投光范围: X向540度,Y向239度,可自动校正定位
扫描速度: X向3.0秒/540度，Y向2.0秒/250度
光束角度: 平行光束角0°-2.3° 雾化光角度8°
频 闪: 双频闪结构 ，0.5-14次/秒可调
马达数量: 14个超静音马达，其中二个三相马达，16Bit驱动
控制方式: 国际标准DMX512
地址码设置: 内置长寿命电池可自动充电，
设置地址码时不需要接通灯具电源
传输方式: 可选装无线DMX512接收模块
通道数量: 多达20个控制通道，双信道接收模式设计
其它功能: 远程控制灯泡开关，风机自动调速，
灯具闭光时自动降低60W灯泡功率
外 观: 耐高温塑料外壳，高强度合金冷压成型内核材料
防护等级: IP20
灯具尺寸: 380X367X522
净 重: 19KG
流明值参数: 20m/186700Lux
40m/48175Lux 60m/20855Lux

SPECIFICATIONS
Voltage: AC100V 240V/50 60Hz
Ballast: electronic ballast
Lamp: OSRAM SIRIUS series HRI 330W
Color Temperature: 8500K
Lamp life: 1500 hours
Color: 14 colors + white
Pattern: 8 + 4 rotation patterns aperture
Prism: two bidirectional rotating prism plate,
beam angle can freely zoom
Lens: high-precision multi-group glued optical lens
Soft effect: adjustable soft angle
Light beam: multi-level beam angle changes effect
Adjusting coke: linear focus
Dimming: 0-100% linear regulator
Spotlights range: X to 540 degrees, Y to 239 degrees,
you can automatically correct positioning
Scan speed: X 3.0 seconds / 540 degrees,
Y to 2.0 secretaryonds / 250 degrees
Beam Angle: the parallel beam angle of 0 - 2.3 °
atomization light angle of 8 °
Strobe: the structure of the double flash,
0.5-14 times / sec adjustable
Motor Quantity: 14 ultra-quiet motor, including
two three-phase motors, 16Bit driver
Control mode: International standard DMX512
Address code setting: built-in long-life battery is automatically
charged and turned on the lamp power, do not need to set
the address code
Transmission mode: optional wireless DMX512 receiver module
Number of Channels: Up to 20 control channels, dual-channel
receiver mode design
Other features: remote control light switch, automatic fan speed
control, lamp power 60W lamps shut off laser automatically reduce
Appearance: high temperature resistant plastic housing,
high-strength alloy cold press molding the core material.
Protection: IP20
Lamp Size: 380X367X522
Net weight: 19KG
Lumens parameters: 20m/186700Lux
40m/48175Lux 60m/20855Lux
